Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Force, SRAM -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite, electronic ready
Suspension Fork
Advanced-grade composite, composite OverDrive 2 steerer, 15mm thru-axle
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Force
Front Derailleur
SRAM Force
Shift Levers
SRAM S-Series HRD700
Cassette
SRAM PG1050 11x28, 10-speed
Crank
Rotor 3DF, 36/46
Bottom Bracket
Rotor 3DF
Chain
KMC X10 SL
Pedals
N/A
Wheels
Front Hub
Giant P-CXR1 WheelSystem, [F] 15mm axle
Rear Hub
Giant P-CXR1 WheelSystem, [F] 15mm axle
Rims
Giant P-CXR1 WheelSystem
Spokes
Giant P-CXR1 WheelSystem
Tires
Schwalbe Super Swan Evo, tubeless ready, 700x35, folding
Brakes
Brakes
SRAM S-Series HRD700, hydraulic disc, size specific rotor diameter
Brake Levers
SRAM S-Series HRD700
Cockpit
Stem
Giant Connect SL, OverDrive 2
Handlebar
Giant Connect SL, 31.8mm
Seat
Saddle
Fi'zi:k Antares, K:ium rails
Seatpost
Giant D-Fuse SL Composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Top Tube Length | 515 mm | 530 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 160 mm | 175 mm | 190 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1008 mm | 1014 mm | 1019 mm | 1030 mm | 1040 mm | 1055 mm |
| Standover Height | 757 mm | 780 mm | 803 mm | 820 mm | 833 mm | 843 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
About this model
TCX Advanced 1 (2014) completes the Giant Tcx model. There are 95 bikes that carry this model name. You can get a glimpse at all models from 2013, by clicking on this link.
Model range prices
The most economical model, the Giant TCX 2 2013 has a starting price of 1050$. Giant TCX Advanced 0 (2014) 2013 on the other hand is the most expensive at 7150$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Cyclocross bikes average price
If you want to purchase a solid Cyclocross bike, it is important to know that the average cost is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Giant released this model in 2013, its price was 4050$. In conclusion, this bike price is 101.29% more expensive than the price of the average Cyclocross bike.
TCX Advanced 1 (2014) components
Fork material
TCX Advanced 1 (2014) has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Giant TCX Advanced 1 (2014) 2013, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant TCX Advanced 1 (2014) has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
TCX Advanced 1 (2014) comes in 6 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
