Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2, Shimano -
Suspension Rigid -
Drivetrain 1 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite
Suspension Fork
Advanced-grade composite, Full-composite OverDrive 2 steerer, 15mm thru-axle
Rear Shock
N / A
Drivetrain
Rear Derailleur
Shimano Ultegra Di2, Electronic
Front Derailleur
NA
Shift Levers
Shimano RS785 Di2, Electronic
Cassette
Shimano Ultegra 11x28, 11-speed
Crank
ROTOR 3D30, 40t NOQX1 ring w/ Giant 1x Chainguide
Bottom Bracket
Press Fit, Rotor 3DF
Chain
KMC X11SL
Pedals
N/A
Wheels
Front Hub
Giant CRX 1 WheelSystem; precision-sealed cartridge bearings, 28h, [F] 15mm axle, [R] 142x12 axle
Rear Hub
Giant CRX 1 WheelSystem; precision-sealed cartridge bearings, 28h, [F] 15mm axle, [R] 142x12 axle
Rims
Giant CRX 1 WheelSystem; 24mm wide, Tubeless compatible, alloy
Spokes
Giant CRX 1 WheelSystem; DT Swiss Competition stainless
Tires
Maxxis Mud Wrestler, 700x33, Tubeless ready, Folding
Brakes
Brakes
Shimano RS785, Hydraulic disc, 140mm
Brake Levers
Shimano RS785, Hydraulic disc
Cockpit
Stem
Giant Contact SL, OverDrive 2
Handlebar
Giant Contact SL, 31.8mm
Seat
Saddle
Fi'zi:k Antares, K:ium rail
Seatpost
Giant D-Fuse SL, Composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.459 mm | 1.483 mm | 1.486 mm | 1.491 mm | 1.485 mm |
| Stack | 540 mm | 556 mm | 572 mm | 589 mm | 603 mm |
| Reach | 370 mm | 375 mm | 385 mm | 395 mm | 406 mm |
| Top Tube Length | 530 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 130 mm | 145 mm | 160 mm | 175 mm | 190 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1014 mm | 1019 mm | 1030 mm | 1040 mm | 1055 mm |
| Standover Height | 757 mm | 803 mm | 820 mm | 833 mm | 843 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
About this model
TCX Advanced Pro 1 completes the Giant Tcx model. 95 bikes variations carry this model name so far. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
Giant TCX Espoir 24 2016 is the cheapest bike model and costs 710$. Giant TCX Advanced Pro 1 2016 is the most expensive one and costs 4500$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Cyclocross bikes
According to our math, the average price for a trustworthy Cyclocross bike is 2012$. However, even if your budget is less than the average, you might still be able to get a top-quality Cyclocross bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Giant released this model in 2016, its price was 4500$. In conclusion, this bike price is 123.66% more expensive than the price of the average Cyclocross bike.
TCX Advanced Pro 1 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on TCX Advanced Pro 1 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The TCX Advanced Pro 1 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
TCX Advanced Pro 1 comes in 5 sizes, that range from 162 cm – 199 cm (5.31 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
