Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Force -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 175cm
MD
171cm - 181cm
MD/LG
177cm - 187cm
LG
182cm - 193cm
XL
189cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-Grade Composite, 12mm axle, flat mount
Suspension Fork
Advanced -Grade composite, full-composite OverDrive 2 steerer
Rear Shock
N / A
Drivetrain
Rear Derailleur
SRAM Force CX1
Front Derailleur
N/A
Shift Levers
SRAM Force CX1
Cassette
SRAM PG1170, 11x36
Crank
SRAM Force CX 1, 40
Bottom Bracket
GXP
Chain
SRAM PC1170
Pedals
N/A
Wheels
Front Hub
Giant CXR-1 WheelSystem
Rear Hub
Giant CXR-1 WheelSystem
Rims
Giant CXR-1 WheelSystem
Spokes
Giant CXR-1 WheelSystem
Tires
Maxxis All-Terrene, 700x33, 120 tpi, folding tubeless tires
Brakes
Brakes
SRAM Force CX1, hydraulic
Brake Levers
SRAM Force CX1
Cockpit
Stem
Giant Contact SL
Handlebar
Giant Contact SL
Seat
Saddle
Giant Contact SL (neutral)
Seatpost
Giant D-Fuse SL, composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.49 mm | 1.49 mm | 1.49 mm | 1.49 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 591 mm | 596 mm | 607 mm | 617 mm | 632 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 68 mm | 65 mm | 62 mm | 59 mm | 59 mm |
| Stack | 538 mm | 554 mm | 570 mm | 587 mm | 601 mm |
| Reach | 368 mm | 373 mm | 383 mm | 393 mm | 404 mm |
| Top Tube Length | 528 mm | 543 mm | 558 mm | 573 mm | 588 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 525 mm | 545 mm | 555 mm | 565 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 130 mm | 145 mm | 160 mm | 175 mm | 190 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1012 mm | 1017 mm | 1028 mm | 1038 mm | 1053 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 781 mm | 801 mm | 819 mm | 830 mm | 841 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 171 cm | 177 cm | 182 cm | 189 cm |
| Rider Max Height | 175 cm | 181 cm | 187 cm | 193 cm | 199 cm |
Model Overview
TCX Advanced Pro 1 is part of the Giant Tcx model. Giant launched 95 bikes of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Giant TCX Espoir 26 2019 is the most affordable bike of this model and has a price of 700$. On the other hand, Giant TCX Advanced Pro 1 2019, is the most expensive and costs 4200$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Cyclocross bikes
Our math shows that the average cost of a dependable Cyclocross bike is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2019 for 4200$. In conclusion, this bike price is 108.75% higher than the price of the average Cyclocross bike.
TCX Advanced Pro 1 components
Fork material
TCX Advanced Pro 1 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the TCX Advanced Pro 1 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The TCX Advanced Pro 1 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 5 sizes. They vary from 165 cm – 199 cm (5.41 ft – 6.53 ft). In short, you can easily find one that suits you.
