Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-Grade Composite, 12mm thru-axle, disc
Suspension Fork
Advanced-Grade Composite, full-composite OverDrive 2 steerer, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano GRX RX-810
Front Derailleur
N/A
Shift Levers
Shimano GRX RX-810, 1x11
Cassette
Shimano Ultegra, 11-speed, 11x34
Crank
Shimano GRX RX-810, 40t S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom Bracket
Shimano, press fit
Chain
KMC X11SL-1
Pedals
N/A
Wheels
Front Hub
Giant SLR 2 Carbon Disc WheelSystem
Rear Hub
Giant SLR 2 Carbon Disc WheelSystem
Rims
Giant SLR 2 Carbon Disc WheelSystem
Spokes
Giant SLR 2 Carbon Disc WheelSystem
Tires
Maxxis All-Terrene, 700x33c, tubeless
Brakes
Brakes
Shimano GRX RX-810 hydraulic, Shimano SM-RT800 rotors [F]160mm, [R]140mm
Brake Levers
Shimano GRX RX-810 hydraulic
Cockpit
Stem
Giant Contact SL S:80mm, M:90mm, M/L:100mm, L:100mm, XL:110mm
Handlebar
Giant Contact SL S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm
Grips
Stratus Lite 3.0
Seat
Saddle
Giant Fleet SL
Seatpost
Giant D-Fuse SLR, composite, -5/+15mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.48 mm | 1.48 mm | 1.49 mm | 1.48 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 591 mm | 597 mm | 607 mm | 617 mm | 632 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 68.3 mm | 65.1 mm | 61.8 mm | 58.6 mm | 58.6 mm |
| Stack | 528 mm | 559 mm | 575 mm | 592 mm | 606 mm |
| Reach | 373 mm | 378 mm | 388 mm | 398 mm | 409 mm |
| Top Tube Length | 533 mm | 548 mm | 563 mm | 578 mm | 593 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 505 mm | 525 mm | 545 mm | 555 mm | 565 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 133 mm | 148 mm | 163 mm | 178 mm | 193 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1017 mm | 1023 mm | 1033 mm | 1043 mm | 1058 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 791 mm | 810 mm | 829 mm | 835 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
Model Overview
TCX Advanced Pro 1 completes the Giant Tcx model. Giant launched 95 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
The most economical model, the Giant TCX Advanced Pro 2 2022 has a starting price of 2419$. Giant TCX Advanced Pro 0 2022 on the other hand is the most expensive at 4585$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Cyclocross bikes average price
If you want to purchase a solid Cyclocross bike, it is important to know that the average cost is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 3438$. If we compare this with the average Cyclocross bike cost we notice that the price is 70.87% higher.
TCX Advanced Pro 1 components
Fork material
TCX Advanced Pro 1 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The TCX Advanced Pro 1 2022 bike is equipped with 700c carbon wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 5 sizes. They vary from 162 cm – 199 cm (5.31 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
