Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Apex, Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite
Suspension Fork
Advanced-grade composite, Hybrid OverDrive steerer
Rear Shock
N / A
Drivetrain
Rear Derailleur
SRAM Apex 1X
Front Derailleur
N/A
Shift Levers
SRAM Apex 1
Cassette
SRAM PG-1130 11x42, 11-Speed
Crank
SRAM S350 1X, X-Sync Chainring, 40t
Bottom Bracket
SRAM GXP
Chain
KMC X11EL-1BPBP
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Disc, Sealed Bearings, 12mm axles, 28h
Rear Hub
Giant Performance Tracker Disc, Sealed Bearings, 12mm axles, 28h
Rims
Giant PX-2 Disc, Tubeless
Spokes
Sapim Race, 14/15g
Tires
Maxxis Rambler, Tubeless, 700x40
Brakes
Brakes
SRAM Apex 1X HRD, hydraulic disc, 160mm
Brake Levers
SRAM Apex 1
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect XR Ergo-Control, 31.8mm
Seat
Saddle
Giant Contact Neutral
Seatpost
Giant D-Fuse, composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.49 mm | 1.49 mm | 1.49 mm | 1.49 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 591 mm | 596 mm | 607 mm | 617 mm | 632 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 68 mm | 65 mm | 62 mm | 59 mm | 59 mm |
| Stack | 538 mm | 554 mm | 570 mm | 587 mm | 601 mm |
| Reach | 368 mm | 373 mm | 383 mm | 393 mm | 404 mm |
| Top Tube Length | 528 mm | 543 mm | 558 mm | 573 mm | 588 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 525 mm | 545 mm | 555 mm | 565 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 130 mm | 145 mm | 160 mm | 175 mm | 190 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1012 mm | 1017 mm | 1028 mm | 1038 mm | 1053 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 756 mm | 801 mm | 819 mm | 830 mm | 841 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
Model Overview
TCX Advanced SX completes the Giant Tcx model. There are 95 bikes that carry this model name. Take a sneak peek at all Giant Tcx bikes models from 2018, by clicking here.
Model range prices
Giant TCX Espoir 24 2018 is the most affordable bike of this model and has a price of 685$. On the other hand, Giant TCX Advanced Pro 1 2018, is the most expensive and costs 3775$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Cyclocross bikes
Our math shows that the average cost of a dependable Cyclocross bike is 2012$. However, even if your budget is less than the average, you might still be able to get a top-quality Cyclocross bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2018 for 2120$. In conclusion, this bike price is 5.37% higher than the price of the average Cyclocross bike.
TCX Advanced SX components
Fork material
TCX Advanced SX has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on TCX Advanced SX are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The TCX Advanced SX comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
TCX Advanced SX comes in 5 sizes, that range from 162 cm – 199 cm (5.31 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
