Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Aluminum -
Wheels 700c -
Suspension Rigid
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum
Suspension Fork
Advanced-Grade Composite, Alloy OverDrive Steerer
Drivetrain
Bottom Bracket
86.5mm shell accepts press-fit style BB only, bearing set not included
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|
| Top Tube Length | 535 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 130 mm | 145 mm | 160 mm | 175 mm | 190 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1016 mm | 1022 mm | 1032 mm | 1042 mm | 1052 mm |
| Standover Height | 787 mm | 805 mm | 826 mm | 841 mm | 861 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 180 cm | 189 cm | 199 cm |
Model Overview
TCX Frameset completes the Giant Tcx model. 95 frames variations carry this model name so far. Check out the entire range from 2013 of this model, by clicking this link.
Model range prices
Giant TCX Frameset 2013 is the most economical model, with a starting price of 750$. Giant TCX Advanced SL (ISP) Frameset 2013 on the other hand costs 4350$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Cyclocross frames
According to our math, the average price for a trustworthy Cyclocross frame is 1405$. However, even though the average price of a Cyclocross frame is lower, you might still be able to get a top-quality frame. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
This frame was released in 2013 and its price was 750$. Comparing this to the average Cyclocross frame price, we see that the price is 87.33% lower.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Sizes
This frame is available in 5 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
