Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SLR-grade aluminum
Suspension Fork
Advanced-grade composite, Hybrid OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano HG-500 11x34, 10-Speed
Crank
FSA Omega, 32/48
Bottom Bracket
FSA Mega Exo
Chain
KMC X10 w/ Missing Link
Wheels
Front Hub
Giant Sport Tracker Disc, 28h
Rear Hub
Giant Sport Tracker Disc, 28h
Rims
Giant SX-2 Disc, Tubeless
Spokes
Sapim Leader, 14g
Tires
Giant Crosscut Gravel 2, 700x40Tubeless
Brakes
Brakes
Giant Conduct, hydraulic disc, 160mm
Brake Levers
Shimano Tiagra
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect XR Ergo-Control
Seat
Saddle
Giant Contact Neutral
Seatpost
Giant D-Fuse, composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.49 mm | 1.5 mm | 1.53 mm | 1.55 mm | 1.58 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 591 mm | 597 mm | 608 mm | 612 mm | 621 mm | 632 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 83 mm | 83 mm | 83 mm | 79 mm | 79 mm | 79 mm |
| Stack | 558 mm | 567 mm | 581 mm | 598 mm | 612 mm | 631 mm |
| Reach | 379 mm | 381 mm | 387 mm | 391 mm | 396 mm | 400 mm |
| Top Tube Length | 537 mm | 547 mm | 557 mm | 572 mm | 587 mm | 597 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 390 mm | 420 mm | 460 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 140 mm | 155 mm | 175 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1038 mm | 1044 mm | 1055 mm | 1060 mm | 1069 mm | 1080 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 704 mm | 727 mm | 760 mm | 784 mm | 809 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
About this model
ToughRoad SLR GX 1 is part of the Giant Toughroad model. Giant launched 23 bikes of this model so far. Take a sneak peek at all Giant Toughroad bikes models from 2018, by clicking here.
Model range prices
The most economical model, the Giant ToughRoad SLR 2 2018 has a starting price of 910$. Giant ToughRoad SLR GX 0 2018 on the other hand is the most expensive at 1735$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Giant released this model in 2018, its price was 1380$. Comparing this to the average Gravel bike price, we see that the price is 78.41% smaller.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on ToughRoad SLR GX 1 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant ToughRoad SLR GX 1 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This bike is available in 6 sizes. They vary from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
