Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM High
163cm - 173cm
SM Low
163cm - 173cm
MD High
170cm - 181cm
MD Low
170cm - 181cm
LG High
178cm - 189cm
LG Low
178cm - 189cm
XL High
186cm - 198cm
XL Low
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum front and rear triangles, 120mm Maestro suspension, flip chip - Maestro, 12x148mm thru-axle
Suspension Fork
Fox 34 Performance, 130mm, GRIP damper, Boost 15x110 Kabolt, 44mm offset, custom tuned for Giant
Rear Shock
Fox Float Performance, 185/50, custom tuned for Giant
Drivetrain
Rear Derailleur
Shimano SLX RD-M7100
Front Derailleur
N/A
Shift Levers
Shimano SLX SL-M7100, 1x12
Cassette
Shimano SLX, 10x51
Crank
Shimano SLX, 30t, 55mm chainline S:165mm, M:170mm, L:170mm, XL:170mm
Bottom Bracket
Shimano, press fit
Chain
KMC X-12
Pedals
platform [GC,GT]
Wheels
Front Hub
alloy, sealed
Rear Hub
alloy, sealed
Rims
Giant AM 29 tubeless ready sleeve-joint rim, 30mm inner width
Spokes
Sapim
Tires
[F] Maxxis Minion DHF 29x2.5 WT, 3C MaxxTerra, EXO, TR [R] Maxxis Aggressor 29x2.5, EXO, TR, tubeless
Brakes
Brakes
Shimano Deore BR-MT520, hydraulic, Shimano RT-56 rotors [F]180mm, [R]180mm
Brake Levers
Shimano BL-MT501
Cockpit
Stem
Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
Handlebar
Giant Contact SL TR35, 780x35mm
Grips
Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm
Seat
Saddle
Giant Romero
Seatpost
Giant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.44 mm | 1.34 mm | 1.38 mm | 1.29 mm | 1.33 mm | 1.22 mm | 1.25 mm |
| Bottom Bracket Height | 339 mm | 329 mm | 339 mm | 329 mm | 339 mm | 329 mm | 339 mm | 329 mm |
| Front Center | 730 mm | 731 mm | 759 mm | 760 mm | 688 mm | 689 mm | 827 mm | 828 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 120 mm | 126 mm | 120 mm | 126 mm | 120 mm | 126 mm | 120 mm | 126 mm |
| Stack | 607 mm | 613 mm | 616 mm | 622 mm | 625 mm | 631 mm | 634 mm | 640 mm |
| Reach | 434 mm | 425 mm | 459 mm | 450 mm | 483 mm | 475 mm | 518 mm | 510 mm |
| Top Tube Length | 562 mm | 564 mm | 600 mm | 602 mm | 627 mm | 629 mm | 664 mm | 666 mm |
| Seat Tube Angle | 78 ° | 77.2 ° | 77 ° | 76.3 ° | 77 ° | 76.3 ° | 77 ° | 76.3 ° |
| Seat Tube Length | 420 mm | 420 mm | 430 mm | 430 mm | 465 mm | 465 mm | 496 mm | 496 mm |
| Head Tube Angle | 66.2 ° | 65.4 ° | 66.2 ° | 65.5 ° | 66.2 ° | 65.5 ° | 66.2 ° | 65.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm | 130 mm | 130 mm |
| Chainstay Length | 440 mm | 442 mm | 440 mm | 442 mm | 440 mm | 442 mm | 440 mm | 442 mm |
| Wheelbase | 1168 mm | 1169 mm | 1197 mm | 1198 mm | 1126 mm | 1127 mm | 1265 mm | 1266 mm |
| Bottom Bracket Drop | 35 mm | 45 mm | 35 mm | 45 mm | 35 mm | 45 mm | 35 mm | 45 mm |
| Standover Height | 741 mm | 733 mm | 737 mm | 728 mm | 762 mm | 752 mm | 784 mm | 774 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 163 cm | 170 cm | 170 cm | 178 cm | 178 cm | 186 cm | 186 cm |
| Rider Max Height | 173 cm | 173 cm | 181 cm | 181 cm | 189 cm | 189 cm | 198 cm | 198 cm |
Model Overview
Trance 29 1 belongs to the Giant Trance model. 139 bikes variations carry this model name so far. Take a sneak peek at all Giant Trance bikes models from 2024, by clicking here.
Model range prices
Giant Trance 29 2 2024 is the cheapest bike model and costs 2530$. Giant Trance 29 1 2024 is the most expensive one and costs 3036$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2024 and its price was 3036$. In conclusion, this bike price is 9.92% higher than the price of the average Trail bike.
Overview of components
Fork
The fork installed on this bike is the Fox Performance Float 34 model. The travel on this model is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is Fox Float Performance, with a travel distance of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The wheels on Trance 29 1 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 8 sizes. They vary from 163 cm – 198 cm (5.35 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Giant Trance 29 1 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
