Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Sektor
-
Groupset Deore, Shimano -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, Advanced Forged composite upper rocker, 140mm Maestro suspension
Suspension Fork
RockShox Sektor Silver Solo Air, Maxle Stealth, Boost, OverDrive, 150mm travel
Rear Shock
RockShox Deluxe RT, Trunnion mount
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano HG50 11x36, 10-speed
Crank
Shimano M627, 24/38
Bottom Bracket
Shimano, Press fit
Chain
KMC X10
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Disc, 28h, [F] Boost 110x15mm, [R] Boost 148x12mm
Rear Hub
Giant Performance Tracker Disc, 28h, [F] Boost 110x15mm, [R] Boost 148x12mm
Rims
Giant XC-1
Spokes
Sapim Race, 14/15g
Tires
[F] Schwalbe Nobby Nic, 27.5x2.35, Performance, Folding [R] Schwalbe Nobby Nic, 27.5x2.25, Performance, Folding
Brakes
Brakes
Shimano M365, hydraulic disc, 180mm
Brake Levers
Shimano M365
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect Trail, 31.8mm
Seat
Saddle
Giant Contact Neutral
Seatpost
Giant Connect, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.44 mm | 1.36 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 674 mm | 694 mm | 725 mm | 748 mm | 774 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 591 mm | 591 mm | 595 mm | 618 mm | 632 mm |
| Reach | 390 mm | 410 mm | 439 mm | 452 mm | 473 mm |
| Top Tube Length | 564 mm | 584 mm | 614 mm | 634 mm | 659 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 370 mm | 380 mm | 431 mm | 482 mm | 507 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 100 mm | 105 mm | 130 mm | 145 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1113 mm | 1133 mm | 1164 mm | 1187 mm | 1213 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 701 mm | 705 mm | 727 mm | 772 mm | 792 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Trance 3 is part of the Giant Trance model. There are 139 bikes that carry this model name. Take a sneak peek at all Giant Trance bikes models from 2017, by clicking here.
Model range prices
The most economical model, the Giant Trance 3 2017 has a starting price of 2100$. Giant Trance Advanced 0 2017 on the other hand is the most expensive at 8050$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Giant Trance 3 price was 2100$. Comparing the average cost of a Trail bike to this one, you will see that Trance 3 price is 31.52% smaller.
Overview of components
Fork
This bike has the RockShox Sektor fork installed. The fork’s travel is 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Giant Trance 3 bike has the RockShox Deluxe RT model installed, and has a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the Trance 3 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Trance 3 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
