Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 135mm -
Fork RockShox 35 Gold RL
-
Groupset SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM High
163cm - 173cm
SM Low
163cm - 173cm
MD High
170cm - 181cm
MD Low
170cm - 181cm
LG High
178cm - 189cm
LG Low
178cm - 189cm
XL High
186cm - 196cm
XL Low
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum front and rear triangles, 135mm Maestro suspension, flip chip - Maestro, 12x148mm thru-axle
Suspension Fork
RockShox 35 Gold RL, 150mm, 44mm offset, 15x110 Maxle Stealth, custom tuned for Giant
Rear Shock
Fox Float DPS Performance, 185/55, custom tuned for Giant
Drivetrain
Rear Derailleur
SRAM SX Eagle
Front Derailleur
N/A
Shift Levers
SRAM SX Eagle, 1x12
Cassette
SRAM SX, 11x50
Crank
SRAM SX, 30t, 55mm chainline S:165mm, M:170mm, L:170mm, XL:170mm
Bottom Bracket
SRAM DUB, press fit
Chain
SRAM SX Eagle
Pedals
N/A
Wheels
Front Hub
alloy, sealed bearing
Rear Hub
alloy, sealed bearing
Rims
Giant AM 29, alloy
Spokes
Sapim
Tires
[F] Maxxis Minion DHF 29x2.5 WT, EXO, TR [R] Maxxis Dissector 29x2.4, EXO, TR, tubeless
Brakes
Brakes
Tektro M745, hydraulic, Tektro rotors [F]203mm, [R]180mm
Brake Levers
Shimano Deore BL-MT401
Cockpit
Stem
Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
Handlebar
Giant Contact SL TR35, 780x35mm, 20mm rise
Grips
Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm
Seat
Saddle
Giant Romero
Seatpost
Giant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm M:
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.45 mm | 1.33 mm | 1.37 mm | 1.27 mm | 1.3 mm | 1.22 mm | 1.25 mm |
| Bottom Bracket Height | 344 mm | 334 mm | 344 mm | 334 mm | 344 mm | 334 mm | 344 mm | 334 mm |
| Front Center | 739 mm | 738 mm | 771 mm | 770 mm | 805 mm | 804 mm | 833 mm | 833 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 119.5 mm | 125.1 mm | 119.5 mm | 125.1 mm | 119.7 mm | 125.1 mm | 119.5 mm | 125.1 mm |
| Stack | 607 mm | 613 mm | 611 mm | 617 mm | 620 mm | 627 mm | 630 mm | 636 mm |
| Reach | 430 mm | 422 mm | 460 mm | 452 mm | 490 mm | 482 mm | 515 mm | 507 mm |
| Top Tube Length | 560 mm | 562 mm | 591 mm | 593 mm | 623 mm | 625 mm | 650 | 652 mm |
| Seat Tube Angle | 77.9 ° | 77.2 ° | 77.9 ° | 77.2 ° | 77.9 ° | 77.2 ° | 77.9 ° | 77.2 ° |
| Seat Tube Length | 430 mm | 430 mm | 430 mm | 430 mm | 465 mm | 465 mm | 496 mm | 496 mm |
| Head Tube Angle | 66.2 ° | 65.5 ° | 66.2 ° | 65.5 ° | 66.2 ° | 65.5 ° | 66.2 ° | 65.5 ° |
| Head Tube Length | 95 mm | 95 mm | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 431 mm | 434 mm | 431 mm | 434 mm | 431 mm | 434 mm | 431 mm | 434 mm |
| Wheelbase | 1168 mm | 1169 mm | 1200 mm | 1201 mm | 1234 mm | 1235 mm | 1262 mm | 1264 mm |
| Bottom Bracket Drop | 30 mm | 40 mm | 30 mm | 40 mm | 30 mm | 40 mm | 30 mm | 40 mm |
| Standover Height | 739 mm | 731 mm | 734 mm | 725 mm | 759 mm | 750 mm | 782 mm | 773 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 163 cm | 170 cm | 170 cm | 178 cm | 178 cm | 186 cm | 186 cm |
| Rider Max Height | 173 cm | 173 cm | 181 cm | 181 cm | 189 cm | 189 cm | 196 cm | 196 cm |
About this model
Trance X 29 2 is part of the Giant Trance model. 139 bikes variations carry this model name so far. You can easily view all of the Giant Trance bikes models from 2023, here.
Model range prices
Giant Trance X 3 2023 is the most economical model, with a starting price of 2747$. Giant Trance Advanced, Pro 29 1 2023 on the other hand costs 6218$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Giant Trance X 29 2 price was 3503$. Comparing this to the average Trail bike price, we see that the price is 26.83% higher.
Trance X 29 2 components
Fork
The RockShox 35 Gold RL is included from the factory. It has a travel distance of 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the Fox Float DPS Performance rear shock model, which has a travel of 135mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Giant Trance X 29 2 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant Trance X 29 2 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 8 sizes available for this model. Rider height can be anywhere between 163 cm – 196 cm (5.35 ft – 6.43 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Giant Trance X 29 2 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
