Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 125mm -
Travel Rear 125mm -
Fork Fox Float 32
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum, 5" Maestro Suspension
Suspension Fork
Fox 32 F125RL (Giant LTD Edition) w/ 15QR Thru Axle and Tapered Steerer, 125mm Travel
Rear Shock
Fox Float R
Drivetrain
Rear Derailleur
Shimano SLX Shadow, Top Normal, 10-Speed
Front Derailleur
Shimano SLX
Shift Levers
Shimano SLX M660 Rapidfire, 3x10 Speed
Cassette
Shimano HG81 11x36, 10-Speed
Crank
Shimano M552, 24/32/42
Bottom Bracket
Shimano Press Fit
Chain
Shimano HG-74
Pedals
Not Included
Wheels
Front Hub
[F] Giant Tracker w/ 15mm Axle, [R] Shimano M475, 32h
Rear Hub
[F] Giant Tracker w/ 15mm Axle, [R] Shimano M475, 32h
Rims
Giant S-XC2
Spokes
[F] 15g, [R] 14g, Stainless
Tires
Kenda Nevegal, 120 tpi, 26x2.1 Folding
Brakes
Brakes
Avid Elixer 3, [F] 185mm [R] 160mm
Brake Levers
Avid Elixer 3
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect, Low Rise 31.8
Seat
Saddle
Fi'zi:k Gobi XM (Giant LTD Edition) w/ Manganese Rails
Seatpost
Giant Connect, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Top Tube Length | 559 mm | 584 mm | 610 mm | 635 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 117 mm | 127 mm | 145 mm | 165 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1082 mm | 1105 mm | 1133 mm | 1158 mm |
| Standover Height | 724 mm | 762 mm | 792 mm | 823 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Trance X3 is part of the Giant Trance model. Giant launched 139 bikes of this model so far. You can get a glimpse at all models from 2011, by clicking on this link.
Model range prices
Giant Trance X4 2011 is the cheapest bike model and costs 1500$. Giant Trance X Advanced SL 0 2011 is the most expensive one and costs 8700$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2011 and its price was 2200$. Comparing this to the average Trail bike price, we see that the price is 25.55% smaller.
Overview of components
Fork
The Fox Float 32 is included from the factory. It has a travel distance of 125mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the Fox Float R model, with a travel of 125mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The Trance X3 2011 bike is equipped with 26″ aluminum wheels when leaving the factory. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant Trance X3 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
