Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Travel Rear 125mm -
Fork RockShox
-
Groupset Deore, Alivio -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum, 5" Maestro Suspension
Suspension Fork
RockShox XC32 TK Coil w/ OverDrive Steerer, 120mm Travel
Rear Shock
Giant Air-R
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
Shimano Alivio
Shift Levers
Shimano Alivio, 3x9 Speed
Cassette
SRAM PG 950 11x34, 9-Speed
Crank
Shimano M542, 22/32/44
Bottom Bracket
Shimano Press Fit
Chain
Shimano HG-73
Pedals
Alloy Platform
Wheels
Front Hub
[F] Giant Tracker Sealed, [R] Giant Tracker Performance, 32h
Rear Hub
[F] Giant Tracker Sealed, [R] Giant Tracker Performance, 32h
Rims
Giant S-XC2
Spokes
Stainless Steel
Tires
Schwalbe Nobby Nic, 26x2.25 Performance
Brakes
Brakes
Avid Elixir 1, [F] 180mm, [R] 160mm
Brake Levers
Avid Elixir 1
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect, Low Rise 31.8
Seat
Saddle
Giant Performance MTB
Seatpost
Giant Connect, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Top Tube Length | 559 mm | 584 mm | 610 mm | 635 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 117 mm | 127 mm | 145 mm | 165 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1082 mm | 1105 mm | 1133 mm | 1158 mm |
| Standover Height | 724 mm | 762 mm | 792 mm | 823 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Trance X4 belongs to the Giant Trance model. 139 bikes variations carry this model name so far. You can get a glimpse at all models from 2012, by clicking on this link.
Model range prices
The most economical model, the Giant Trance X4 2012 has a starting price of 1550$. Giant Trance X Advanced SL 0 2012 on the other hand is the most expensive at 8600$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2012 for 1550$. Comparing the average cost of a Trail bike to this one, you will see that Trance X4 price is 78.19% lower.
Overview of components
Fork
Giant Trance X4 2012 bike is equipped with the RockShox fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The Trance X4 has a rear shock with a travel of 125mm. The model Giant Air-R is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When leaving the production line, the Trance X4 model has 26″ aluminum wheels. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant Trance X4 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Giant Trance X4 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
