Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XS
160cm - 172cm
SM
166cm - 178cm
MD
172cm - 184cm
LG
179cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-Grade Composite
Suspension Fork
Advanced-Grade Composite, alloy OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano TT SL-BSR 1
Cassette
Shimano 105, 11x28
Crank
Shimano FC-RS510, 34/50
Bottom Bracket
Shimano, press fit
Chain
KMC X11EL-1
Pedals
platform pedal [GCS,GTS] N/A [all other GSC]
Wheels
Front Hub
Giant S-R2 wheelset
Rear Hub
Giant S-R2 wheelset
Rims
Giant S-R2 wheelset
Spokes
Giant S-R2 wheelset
Tires
Giant Gavia Course AC 1, tubeless, 700x25c (28mm), folding
Brakes
Brakes
Front: TKB84 rear: TBK88
Brake Levers
Tektro RX 4.1
Cockpit
Stem
Giant Connect
Handlebar
Giant alloy Contact base bar aluminum extension ski bend
Seat
Saddle
ISM PS1.0, steel rail
Seatpost
Trinity composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.22 mm | 1.25 mm | 1.3 mm | 1.35 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 571 mm | 592 mm | 607 mm | 622 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 61 mm | 61 mm | 61 mm | 61 mm |
| Stack | 474 mm | 502 mm | 531 mm | 560 mm |
| Reach | 390 mm | 402 mm | 409 mm | 415 mm |
| Top Tube Length | 501 mm | 520 mm | 533 mm | 546 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 460 mm | 490 mm | 515 mm | 545 mm |
| Head Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 80 mm | 110 mm | 140 mm | 170 mm |
| Chainstay Length | 397 mm | 397 mm | 397 mm | 397 mm |
| Wheelbase | 959 mm | 980 mm | 995 mm | 1010 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 734 mm | 759 mm | 782 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 166 cm | 172 cm | 179 cm |
| Rider Max Height | 172 cm | 178 cm | 184 cm | 193 cm |
Model Overview
Trinity Advanced is part of the Giant Trinity model. There are 68 bikes that carry this model name. Take a sneak peek at all Giant Trinity bikes models from 2021, by clicking here.
Model range prices
Giant Trinity Advanced 2021 is the cheapest bike model and costs 2650$. Giant Trinity Advanced Pro 1 2021 is the most expensive one and costs 5278$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Triathlon bikes average price
Our math shows that the average cost of a dependable Triathlon bike is 4177$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Triathlon bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2021 and its price was 2650$. In conclusion, this bike price is 57.62% lower than the price of the average Triathlon bike.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The Trinity Advanced 2021 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant Trinity Advanced is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 4 sizes. They vary from 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, finding one for you shouldn’t be a problem.
