Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 130mm -
Fork RockShox Judy Silver TK
-
Groupset SX Eagle -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
163cm - 173cm
MD
170cm - 181cm
LG
178cm - 189cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-Grade Composite with horizontal dropouts
Suspension Fork
RockShox Judy Silver TK 29", Solo Air, 130mm, Boost 15X110, Maxle Stealth, tapered
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM SX Eagle
Front Derailleur
N/A
Shift Levers
SRAM SX Eagle
Cassette
SRAM SX Eagle, 11x50
Crank
SRAM SX Eagle DUB, 32t
Bottom Bracket
SRAM DUB, press fit
Chain
SRAM SX Eagle
Pedals
N/A
Wheels
Front Hub
Giant Tracker Performance, sealed bearing
Rear Hub
Giant Tracker Performance, sealed bearing
Rims
Giant AM+ 27.5” tubeless ready sleeve-joint rim, 35mm inner width
Spokes
Sapim
Tires
Maxxis Rekon+ 27.5x2.8, EXO, TR, tubeless
Brakes
Brakes
Shimano MT400
Brake Levers
Shimano MT401
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect Trail, 780x31.8
Seat
Saddle
Giant Contact (neutral)
Seatpost
JD YSP11 dropper post with remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.52 mm | 1.51 mm | 1.47 mm |
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm | 300 mm |
| Front Center | 666 mm | 680 mm | 694 mm | 715 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 88 mm | 88 mm | 88 mm | 88 mm |
| Stack | 625 mm | 625 mm | 635 mm | 644 mm |
| Reach | 395 mm | 410 mm | 421 mm | 438 mm |
| Top Tube Length | 595 mm | 615 mm | 635 mm | 655 mm |
| Seat Tube Angle | 72 ° | 71.5 ° | 71 ° | 71 ° |
| Seat Tube Length | 390 mm | 440 mm | 490 mm | 535 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1100 mm | 1114 mm | 1128 mm | 1149 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 747 mm | 771 mm | 803 mm | 833 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 163 cm | 170 cm | 178 cm | 186 cm |
| Rider Max Height | 173 cm | 181 cm | 189 cm | 198 cm |
About this model
XTC Advanced + completes the Giant Xtc model. Giant launched 151 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Giant XTC Jr 20 C/B 2020 is the most economical model, with a starting price of 270$. Giant XTC Advanced SL 29 0 2020 on the other hand costs 7784$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2020 for 2300$. Comparing the average cost of a Trail bike to this one, you will see that XTC Advanced + price is 20.09% smaller.
Overview of components
Fork
The XTC Advanced + comes factory-installed with the RockShox Judy Silver TK fork. This has a travel range of 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on XTC Advanced + are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The XTC Advanced + comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 163 cm – 198 cm (5.35 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Giant model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
