Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 120mm -
Fork Fox Performance Elite Float 32
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite
Suspension Fork
Fox 32 Float Performance Elite, FIT4 damper, Kabolt, 15mm thru-axle, OverDrive, 120mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM NX
Front Derailleur
N/A
Shift Levers
SRAM NX
Cassette
SRAM NX 11x42, 11-speed
Crank
SRAM NX, 30T
Bottom Bracket
SRAM GXP, Press fit
Chain
KMC X11
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Disc, 28h, [F] 15mm thru-axle, [R] 142x12mm
Rear Hub
Giant Performance Tracker Disc, 28h, [F] 15mm thru-axle, [R] 142x12mm
Rims
Giant XC-1
Spokes
Sapim Race, 14/15g
Tires
[F] Schwalbe Nobby Nic, 27.5x2.25, Performance, Folding [R] Schwalbe Racing Ralph, 27.5x2.25, Performance, Folding
Brakes
Brakes
Shimano M447, hydraulic disc, [F] 180mm [R] 160mm
Brake Levers
Shimano M605
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect Trail, 31.8mm
Seat
Saddle
Giant Contact Neutral
Seatpost
Tranz X YSP-11 Dropper Post w/ under bar remote, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.49 mm | 1.45 mm | 1.42 mm | 1.37 mm |
| Bottom Bracket Height | 312 mm | 312 mm | 312 mm | 312 mm | 312 mm |
| Front Center | 634 mm | 659 mm | 669 mm | 689 mm | 714 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 95 mm | 95 mm | 95 mm | 95 mm | 95 mm |
| Stack | 588 mm | 588 mm | 593 mm | 603 mm | 612 mm |
| Reach | 374 mm | 394 mm | 409 mm | 424 mm | 446 mm |
| Top Tube Length | 559 mm | 579 mm | 599 mm | 619 mm | 644 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 350 mm | 390 mm | 440 mm | 490 mm | 520 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 95 mm | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1061 mm | 1086 mm | 1096 mm | 1117 mm | 1142 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 705 mm | 727 mm | 747 mm | 780 mm | 804 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
XTC Advanced SX belongs to the Giant Xtc model. There are 151 bikes that carry this model name. Take a sneak peek at all Giant Xtc bikes models from 2017, by clicking here.
Model range prices
Giant XtC Jr 20 Lite 2017 is the most affordable bike of this model and has a price of 260$. On the other hand, Giant XTC Advanced 29 0 2017, is the most expensive and costs 7200$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Giant XTC Advanced SX price was 2575$. Comparing the average cost of a Trail bike to this one, you will see that XTC Advanced SX price is 7.26% smaller.
Overview of components
Fork
Giant XTC Advanced SX 2017 bike is equipped with the Fox Performance Elite Float 32 fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Giant XTC Advanced SX 2017, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The XTC Advanced SX comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Giant XTC Advanced SX bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the XTC Advanced SX. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
