Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 190mm -
Travel Rear 200mm -
Fork Fox Factory Float 49
-
Groupset Saint -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
LTS Downhill Design, FOC Carbon 29" Frame, 200mm Travel w/Forged Linkage, Pivots, 1.5" Head Tube, and 12 x 148mm Thru Axle Dropouts
Suspension Fork
Fox Float Factory 49, 190mm, Adjustable High Speed/Low Speed Compression and Rebound Adj. 20x110mm Boost Thru Axle
Rear Shock
Fox Float Factory X2, 225x75 Metric Trunnion, Air, Adjustable High Speed/Low Speed Compression, High Speed/Low Speed Rebound
Drivetrain
Rear Derailleur
Shimano Saint Shadow Plus, RD-M820, Direct Mount
Front Derailleur
N/A
Shift Levers
Shimano Saint, SL-M820, 1x10
Cassette
Shimano CS-5700, 11-25, 10-speed
Crank
Shimano Saint, FC-M825, 165mm, w/ 36T Ring
Bottom Bracket
Shimano Saint, 83mm
Chain
Shimano CN-HG96, 10-speed
Chain Guide
Custom e*thirteen
Pedals
None
Wheels
Front Hub
All Terra Sealed Bearing 20x110 Boost DH front, 12x148 rear, 6 bolt
Rear Hub
Front: All Terra DH, sealed bearing, 20x110 Boost, Rear: All Terra DH, 6-bolt disc, Boost 12x148mm
Rims
Stan's Flow MK3, 32h, tubeless ready
Spokes
DT Swiss Alpine II, 2.3/2.0 Stainless
Tires
Schwalbe Magic Mary Downhill 29 x 2.35" Addix Ultra Soft compound
Brakes
Brakes
Shimano Saint BR-M820 hydro disc, 203/203mm SM-RT86 IceTech Rotors, Metallic Pads and Fins
Brake Levers
Shimano Saint, BL-M821
Cockpit
Stem
Race Face Atlas Direct Mount, 30/50mm Length
Handlebar
Race Face Atlas, 31.8 Clamp, 1.5" Rise, 785mm
Grips
GT Statement2 Double Lock-on Grips
Headset
GT Fury Internal Headset, 1.5" to 1-1/8" Reducer, Alloy Cups w/ Sealed Bearings
Seat
Saddle
Fabric Scoop Shallow Elite, cro-mo rails
Seatpost
Race Face Turbine, 31.6 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.31 mm |
| Bottom Bracket Height | 448 mm | 448 mm |
| Stack | 618.7 mm | 618.7 mm |
| Reach | 448 mm | 473 mm |
| Top Tube Length | 598 mm | 623 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° |
| Seat Tube Length | 420 mm | 440 mm |
| Head Tube Angle | 62 ° | 62 ° |
| Head Tube Length | 105 mm | 105 mm |
| Chainstay Length | 443 mm | 443 mm |
| Wheelbase | 1262 mm | 1287 mm |
| Bottom Bracket Drop | -74 mm | -74 mm |
| Standover Height | 723 mm | 743 mm |
| Wheels | 29" | 29" |
Model Overview
Fury Carbon Team 29 belongs to the Gt Fury model. There are 25 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
GT Fury Carbon Expert 27.5 2019 is the cheapest bike model and costs 4200$. GT Fury Carbon Team 29 2019 is the most expensive one and costs 7900$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Downhill bikes
Our math shows that the average cost of a dependable Downhill bike is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When GT released this model in 2019, its price was 7900$. Doing a quick comparison, we notice that Fury Carbon Team 29 price is 132.97% higher than the average cost of a Downhill bike.
Overview of components
Fork
The fork installed on this bike is the Fox Factory Float 49 model. The travel on this model is 190mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
GT Fury Carbon Team 29 bike has the Fox Float Factory X2 model installed, and has a travel of 200mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the Fury Carbon Team 29 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fury Carbon Team 29 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
