Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 600 -
Suspension Rigid -
Motor MAHLE 250W 40Nm hub-drive -
Battery MAHLE ebikemotion X35 250Wh -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
All New Grade Alloy 700c Frame, Mahle Ebikemotion specific design, Internal Battery, Tapered Head Tube
Suspension Fork
GT Grade E-Carbon, 1.5" Tapered Carbon Steerer, Flat Mount Disc, 12x100 Thru-Axle
Drivetrain
Rear Derailleur
Shimano GRX, Shadow Plus
Cassette
Shimano HG500, 11-34, 10-speed
Crank
Shimano GRX, 46/30
Bottom Bracket
Shimano BSA RS500
Chain
KMC X10, 10-speed
Wheels
Front Hub
Formula CRX-512, 12x100
Rear Hub
eBikemotion X35
Rims
Shining, 32h
Spokes
Stainless Steel, 13g
Tires
WTB Resolute Comp, 700 x 42, Tubeless Ready
Brakes
Brakes
Shimano GRX 400 Hydro Disc, 160/160mmRT56 Rotors
Cockpit
Stem
GT All Terra 3D Forged Alloy, 31.8
Handlebar
GT Butted 6061 Alloy, 16° Flare Drop
Grips
GT Grip Bar Tape w/Gel, 3.5mm
Headset
1.5" Lower to 1-1/8" Upper w/ Reducer, 25mm Alloy Top Cap
Seat
Saddle
Fabric Scoop Shallow/ Sport, Steel Rails
Seatpost
GT All Terra Two Bolt Alloy
Motor & Battery
Motor
MAHLE ebikemotion X35 250W
Battery
MAHLE ebikemotion X35 250Wh
Charger
X35 Charger
About this model
Grade Bolt is a Gt E Grade model. GT launched 9 e-bikes of this model so far. Take a sneak peek at all Gt E Grade e-bikes models from 2021, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel e-bikes average price
Our math shows that the average cost of a dependable Gravel e-bike is 3642$. However, this doesn’t mean that if you spend less money on a Gravel e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Grade Bolt components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your e-bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The Grade Bolt 2021 e-bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. GT Grade Bolt is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
GT Grade Bolt 2021 is available in one size only. In short, make sure you double-check if it fits you.
