Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800 -
Suspension Rigid -
Motor MAHLE 250W 40Nm hub-drive -
Battery MAHLE ebikemotion X35 250Wh -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
All New Grade Alloy 700c Frame, Mahle Ebikemotion specific design, Internal Battery, Tapered Head Tube
Suspension Fork
GT Grade E-Carbon, 1.5" Tapered Carbon Steerer, Flat Mount Disc, 12x100 Thru-Axle
Drivetrain
Rear Derailleur
Shimano GRX, Shadow Plus
Cassette
Shimano HG500, 11-34, 10-speed
Crank
Shimano GRX, 46/30
Bottom Bracket
Shimano BSA RS500
Chain
KMC X10, 10-speed
Wheels
Front Hub
Formula CRX-512, 12x100
Rear Hub
eBikemotion X35
Rims
Shining, 32h
Spokes
Stainless Steel, 13g
Tires
WTB Resolute Comp, 700 x 42, Tubeless Ready
Brakes
Brakes
Shimano GRX 400 Hydro Disc, 160/160mmRT56 Rotors
Cockpit
Stem
GT All Terra 3D Forged Alloy, 31.8
Handlebar
GT Butted 6061 Alloy, 16° Flare Drop
Grips
GT Grip Bar Tape w/Gel, 3.5mm
Headset
1.5" Lower to 1-1/8" Upper w/ Reducer, 25mm Alloy Top Cap
Seat
Saddle
Fabric Scoop Shallow/ Sport, Steel Rails
Seatpost
GT All Terra Two Bolt Alloy
Motor & Battery
Motor
MAHLE ebikemotion X35 250W
Battery
MAHLE ebikemotion X35 250Wh
Charger
X35 Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Grade Bolt belongs to the Gt E Grade model. 9 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
GT Grade Current 2023 is the cheapest e-bike model and costs 3300$. GT Grade Bolt 2023 is the most expensive one and costs 4000$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel e-bikes
Our math shows that the average cost of a dependable Gravel e-bike is 3642$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 4000$. If we compare this with the average Gravel e-bike cost we notice that the price is 9.83% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
When it comes to the fork, this e-bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the Grade Bolt model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
