Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 160mm -
Fork RockShox Yari RC
-
Groupset GX, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
COR Enduro Design, 6069-T6 Alloy 27.5 Frame, 160mm Travel Independent Drivetrain? Suspension System w/Forged Linkage, Pivots, 1.5" Head Tube, and 12x142mm Thru Axle Dropouts
Suspension Fork
RockShox Yari RC Boost, 170mm Travel, 15mm QR Dropout, Air Spring w/ Rebound & CompressionAdjust, Tapered Alloy Steerer
Rear Shock
RockShox Monarch R Plus Debonair, 8.5"x2.5" Air Shock, w/ Rebound & Compression Adjust
Drivetrain
Rear Derailleur
SRAM GX 1x11 Speed Long Cage
Front Derailleur
N/A
Shift Levers
SRAM GX 1x11 Speed Trigger, Right Side Only
Cassette
Sunrace CSMS8, 11-Speed, 11-46T
Crank
RaceFace Ride, 32T Narrow Wide
Bottom Bracket
RaceFace X-Type
Chain
KMC X11-1
Chain Guide
e*thirteen TRS
Pedals
None
Wheels
Front Hub
(F) All Terra Tall Flange Alloy Disc, Sealed Bearing, 15x110mm Thru Axle, (R) All Terra Alloy Disc, 12x142 mm Thru Axle
Rear Hub
Front: All Terra alloy, 15mm x 110mm, Rear: All Terra alloy, 12mm x 148mm
Rims
WTB STP i29, Tubeless Compatible
Spokes
14/15 gauge stainless
Tires
Schwalbe Magic Mary Performance, TL-Ready, 27.5x2.35" (F/R)
Brakes
Brakes
(F) SRAM Guide R, w/ Metallic Pad, w/ Rotor G2 200mm, (R) SRAM Guide R, w/ Metallic Pad, w/ Rotor G2 180mm
Brake Levers
SRAM
Cockpit
Stem
RaceFace Aeffect, 40mm Length
Handlebar
RaceFace Chester, 20mm Rise, 780mm Width
Grips
GT Statement Double Lock-on Grips
Headset
FSA Orbit 1.5ZS SC
Seat
Saddle
WTB Silverado Sport
Seatpost
All Terra Dropper post, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.38 mm | 1.32 mm | 1.28 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Stack | 590 mm | 599 mm | 609 mm | 618 mm |
| Reach | 410 mm | 434 mm | 460 mm | 484 mm |
| Top Tube Length | 574 mm | 601 mm | 629 mm | 656 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 450 mm | 470 mm | 485 mm | 510 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1156 mm | 1185 mm | 1214 mm | 1243 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm | 10 mm |
| Standover Height | 733 mm | 743 mm | 743 mm | 744 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Sanction Expert completes the Gt Sanction model. GT launched 4 bikes of this model so far. Take a sneak peek at all Gt Sanction bikes models from 2018, by clicking here.
Model range prices
GT Sanction Expert 2018 is the cheapest bike model and costs 3399$. GT Sanction Pro 2018 is the most expensive one and costs 4199$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, GT Sanction Expert price was 3399$. In conclusion, this bike price is 5.88% smaller than the price of the average Enduro bike.
Sanction Expert components
Fork
This bike has the RockShox Yari RC fork installed. The fork’s travel is 170mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
The Sanction Expert has a rear shock with a travel of 160mm. The model RockShox Monarch R Plus Debonair is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
As for the wheels, GT Sanction Expert 2018, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Sanction Expert has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
GT Sanction Expert bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
GT Sanction Expert includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
