Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork RockShox Sektor
-
Groupset NX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
All New Sensor Carbon, 130mm rear wheel travel, carbon front/alloy rear frame, Boost 148 rear spacing, ISCG05 mounts, sealed bearing LockR pivots, Metric Trunnion shock mounts, coil shock compatible
Suspension Fork
RockShox Sektor RL, 130mm DebonAir, 15x110mm, tapered steerer
Rear Shock
RockShox Deluxe R, 130mm, DebonAir, Metric Trunnion
Drivetrain
Rear Derailleur
SRAM NX Eagle
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle
Cassette
SRAM PG 1230 Eagle 11-50t
Crank
Truvativ Descendant 6K, Dub, 32T
Bottom Bracket
SRAM Dub, 73mm BSA
Chain
SRAM Eagle 12spd
Pedals
None included
Wheels
Front Hub
All Terra Alloy Disc 15x110 front, 12x148 rear
Rear Hub
All Terra Alloy Disc, Boost front or rear
Rims
WTB ST i29 TCS 2.0, 32h, tubeless ready
Spokes
Stainless Steel, 14g
Tires
Schwalbe Nobby Nic Performance 29 x 2.35", tubeless ready
Brakes
Brakes
SRAM Level TL hydro disc, 180/180 Centerline Rotors
Brake Levers
SRAM Level TL hydro disc
Cockpit
Stem
All Terra, 1-1/8" Threadless, 3D Forged, 31.8mm, 7° Rise, 60mm
Handlebar
All Terra Alloy Riser, Double-butted 6061, 15mm rise, 780mm
Grips
New GT Statement Single Lock-on Grips
Headset
FSA Orbit C-40-ACB
Seat
Saddle
WTB Silverado Sport
Seatpost
X-Fusion Dropper Post w/ 1x Lever, 31.6, 125mm (S-M) 150mm (L-XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS High | SM High | MD High | LG High | XL High |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.41 mm | 1.34 mm | 1.29 mm | 1.23 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm | 349 mm |
| Stack | 579 mm | 579 mm | 587 mm | 594 mm | 601 mm |
| Reach | 387 mm | 412 mm | 437 mm | 462 mm | 487 mm |
| Top Tube Length | 534 mm | 559 mm | 585 mm | 612 mm | 639 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 392 mm | 400 mm | 430 mm | 480 mm | 520 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 102 mm | 102 mm | 110 mm | 118 mm | 126 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1133 mm | 1158 mm | 1186 mm | 1214 mm | 1243 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 734 mm | 742 mm | 752 mm | 762 mm | 797 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Sensor Carbon Elite is part of the Gt Sensor model. 38 bikes variations carry this model name so far. You can easily view all of the Gt Sensor bikes models from 2019, here.
Model range prices
GT Sensor Alloy Sport 2019 is the most affordable bike of this model and has a price of 1900$. On the other hand, GT Sensor Carbon Pro 2019, is the most expensive and costs 5250$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When GT released this model in 2019, its price was 3150$. Comparing the average cost of a Trail bike to this one, you will see that Sensor Carbon Elite price is 14.05% higher.
Overview of components
Fork
This bike has the RockShox Sektor fork installed. The fork’s travel is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
GT Sensor Carbon Elite bike has the RockShox Deluxe R model installed, and has a travel of 130mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Sensor Carbon Elite are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. GT Sensor Carbon Elite is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
The GT model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
