Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Lyrik Ultimate
-
Groupset X01 Eagle, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
164cm - 179cm
LG
176cm - 187cm
XL
184cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sensor Carbon 29” Frame, 140mm Travel, 12x148mm Thru-Axle, UDH
Suspension Fork
RockShox Lyrik Ultimate RC2, 150mm, Charger 3, DebonAir+ w/ ButterCups, 44mm Offset
Rear Shock
RockShox Super Deluxe Ultimate RC2T, 185x55mm Trunnion
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Shift Levers
SRAM GX Eagle, 12-Speed
Cassette
SRAM XG-1275, 10-52T
Crank
Truvativ Descendant 6K, DUB, 32T
Bottom Bracket
SRAM DUB BSA, 73mm
Chain
SRAM GX Eagle, 12-Speed
Pedals
Not included
Wheels
Front Hub
Formula, 15x110mm
Rear Hub
SRAM MTH746, 12x148mm, XD Driver
Rims
WTB KOM Trail i30, 32h, Tubeless Ready
Tires
Front: Continental Kryptotal Fr, 29x2.4", Enduro Soft, Rear: Continental Kryptotal Fr, 29x2.4", Enduro Soft
Brakes
Brakes
SRAM Code RSC, 200/180mm Centerline Rotors
Cockpit
Stem
GT Alloy, 45mm
Handlebar
GT Alloy Riser Bar, 30mm Rise, 780mm, 5° Up, 8° Back
Grips
GT Mushroom
Headset
FSA No.42
Seat
Saddle
WTB Silverado
Seatpost
TranzX +Rad, 31.6mm, Adjustable Height (S - 150mm, M - 170mm, L/XL - 200mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.34 mm | 1.27 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 754 mm | 783 mm | 812 mm | 851 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 128 mm | 128 mm | 128 mm | 128 mm |
| Stack | 621 mm | 630 mm | 639 mm | 648 mm |
| Reach | 427 mm | 452 mm | 477 mm | 512 mm |
| Top Tube Length | 571 mm | 598 mm | 625 mm | 663 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 380 mm | 400 mm | 420 mm | 460 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1188 mm | 1218 mm | 1247 mm | 1286 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 712 mm | 722 mm | 732 mm | 742 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 164 cm | 176 cm | 184 cm |
| Rider Max Height | 167 cm | 179 cm | 187 cm | 198 cm |
Model Overview
Sensor Carbon Pro LE completes the Gt Sensor model. 38 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the GT Sensor Sport 2023 has a starting price of 2300$. GT Sensor Carbon Pro LE 2023 on the other hand is the most expensive at 5750$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5750$. In conclusion, this bike price is 108.18% more expensive than the price of the average Trail bike.
Sensor Carbon Pro LE components
Fork
The fork installed on this bike is the RockShox Lyrik Ultimate model. The travel on this model is 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
GT Sensor Carbon Pro LE bike has the RockShox Super Deluxe Ultimate RC2T model installed, and has a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
As for the wheels, GT Sensor Carbon Pro LE 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. GT Sensor Carbon Pro LE has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Sensor Carbon Pro LE comes in 4 sizes, that range from 152 cm – 198 cm (4.99 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
