Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 29" -
Suspension Hardtail
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revved Carbon front triangle and swingarm. Alloy seatstay.
Suspension Fork
None
Rear Shock
None 160 mm
Drivetrain
Bottom Bracket
73 mm BSA threaded
Wheels
Tires
Front: None, Rear: None
Brakes
Brakes
None
Cockpit
Stem
None
Handlebar
None
Grips
None
Seat
Saddle
None
Seatpost
30.9 mm with stealth dropper routing
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Size 2 | Size 3 | Size 4 |
|---|---|---|---|
| Stack Reach Ratio | 1.392 mm | 1.353 mm | 1.313 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm |
| Stack | 618 mm | 636 mm | 654 mm |
| Reach | 444 mm | 470 mm | 498 mm |
| Top Tube Length | 600 mm | 630 mm | 666 mm |
| Seat Tube Angle | 76.1 ° | 76 ° | 75.9 ° |
| Seat Tube Length | 400 mm | 430 mm | 480 mm |
| Head Tube Angle | 63.6 ° | 63.6 ° | 63.6 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1239 mm | 1273 mm | 1311 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm |
| Standover Height | 743 mm | 744 mm | 745 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
Gnarvana – Frameset belongs to the Guerrillagravity Gnarvana model. There are 12 frames that carry this model name. Take a sneak peek at all Guerrillagravity Gnarvana frames models from 2023, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro frames
If you want to purchase a solid Enduro frame, it is important to know that the average cost is 1895$. However, even though the average price of an Enduro frame is lower, you might still be able to get a top-quality frame. As a general rule of thumb, you should always read reviews about the frame and its components before buying it to ensure you don’t pay too much.
Overview of components
Dropper post
A dropper post is included with the Gnarvana – Frameset. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
