Guerrilla Gravity Pedalhead – Rally 2023
2023 Mountain
Estimate price |
3,995$
Weight | 13.11 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 140mm -
Fork RockShox Pike Ultimate
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
custom square-profile steel tubeset
Suspension Fork
RockShox Pike Ultimate RC2 MY22- 130 mm
Rear Shock
undefined undefined
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle
Cassette
SRAM XG-1275 Eagle 10-52T
Crank
SRAM GX Carbon Eagle DUB - 170 mm - 32T
Bottom Bracket
73 mm BSA threaded
Chain
SRAM GX Eagle
Wheels
Rims
Crankbrothers Synthesis XCT Alloy
Tires
Maxxis Dissector 3C/EXO/TR 29 x 2.4/, Maxxis Dissector 3C/EXO/TR 29 x 2.4
Brakes
Brakes
SRAM G2 RSC
Cockpit
Stem
e*thirteen Base - 50mm
Handlebar
e*thirteen Race Carbon - 800mm
Grips
ODI Elite Pro
Seat
Saddle
SDG Radar MTN Steel GG Custom
Seatpost
SDG Tellis - 150 mm (S2, S3); 170 mm (S4)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Size 2 | Size 3 | Size 4 |
|---|---|---|---|
| Stack Reach Ratio | 1.437 mm | 1.378 mm | 1.344 mm |
| Bottom Bracket Height | 325 mm | 325 mm | 325 mm |
| Stack | 625 mm | 634 mm | 652 mm |
| Reach | 435 mm | 460 mm | 485 mm |
| Top Tube Length | 608 mm | 636 mm | 666 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 430 mm | 460 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 105 mm | 115 mm | 130 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1189 mm | 1218 mm | 1251 mm |
| Bottom Bracket Drop | 49 mm | 49 mm | 49 mm |
| Standover Height | 706 mm | 719 mm | 732 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
Pedalhead – Rally completes the Guerrillagravity Pedalhead model. Guerrilla Gravity released 15 bikes variations of this model so far. Take a sneak peek at all Guerrillagravity Pedalhead bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Guerrilla Gravity Pedalhead – Ride 2023 has a starting price of 2995$. Guerrilla Gravity Pedalhead – Race 2023 on the other hand is the most expensive at 4795$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2023 and its price was 3995$. In conclusion, this bike price is 44.64% more expensive than the price of the average Trail bike.
Trail bikes average weight
Trail bikes weigh an average of 12.88 kg (28.4 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 13.11 kg (28.9 lbs), Guerrilla Gravity bike is slightly heavier than average. In other words, this model is 1.79% heavier than the average Trail bike.
Overview of components
Fork
The fork installed on this bike is the RockShox Pike Ultimate model. The travel on this model is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the Pedalhead – Rally model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Guerrilla Gravity Pedalhead – Rally has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Dropper post
The Guerrilla Gravity model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
