Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 27.5" -
Suspension Hardtail
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revved Carbon front and alloy rear triangle
Suspension Fork
None
Rear Shock
None 130/140 mm
Drivetrain
Bottom Bracket
73 mm BSA threaded
Wheels
Rims
None
Tires
Front: None, Rear: None
Brakes
Brakes
None
Cockpit
Stem
None
Handlebar
None
Grips
None
Seat
Saddle
None
Seatpost
30.9 mm with stealth dropper routing
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Size 2 | Size 3 | Size 4 |
|---|---|---|---|
| Stack Reach Ratio | 1.305 mm | 1.275 mm | 1.236 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm |
| Stack | 604 mm | 622 mm | 640 mm |
| Reach | 463 mm | 488 mm | 518 mm |
| Top Tube Length | 600 mm | 625 mm | 655 mm |
| Seat Tube Angle | 77.6 ° | 77.5 ° | 77.4 ° |
| Seat Tube Length | 400 mm | 430 mm | 480 mm |
| Head Tube Angle | 65.4 ° | 65.4 ° | 65.4 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1199 mm | 1232 mm | 1271 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm |
| Standover Height | 722 mm | 724 mm | 726 mm |
| Wheels | 27" | 27" | 27" |
About this model
Shred Dogg – Frameset belongs to the Guerrillagravity Shred model. Guerrilla Gravity released 21 frames variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro frames average price
According to our calculations, the average cost of an Enduro frame that is reliable is 1895$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro frame. In conclusion, always check frame reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Dropper post
A dropper post is included with the Shred Dogg – Frameset. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
