Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Fork Öhlins RXF36
-
Groupset XX1 Eagle AXS -
Suspension Full -
Motor Yamaha 250W 80Nm mid-drive -
Battery Yamaha, 600 Wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, AllMtn i600, Carbon
Suspension Fork
Öhlins, RXF36, Air, Travel= 160 mm, Aluschaft 1 1/8 - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Rear Shock
Öhlins, TTX Air Extended, Air, Trunnion Mount M8x25
Drivetrain
Rear Derailleur
SRAM, XX1 Eagle AXS
Shift Levers
SRAM, Eagle XX1 AXS, Trigger switch, 12 Speed
Cassette
SRAM, Eagle XG1295, 10 - 52 teeth
Crank
Haibike Components, Aluminium, 38 teeth
Bottom Bracket
Integrated in the motor
Chain
SRAM, XX1 Eagle Gold
Chain Guide
Haibike aluminium/Nylon directmount
Wheels
Rims
DT Swiss, HXC1200 Carbon
Tires
Maxxis, Minion DHF II, 63-622, 29" x 2.5"
Brakes
Brakes
hydraulicDisc
Brake Levers
Shimano, XTR M9120, Aluminium, Adjustable grip width
Cockpit
Stem
Haibike Components, TheStem 2, A-head, Bar bore: 31.8 mm
Handlebar
Raceface, Six C Carbon, 785 mm
Grips
Raceface, Half Nelson
Headset
Acros, BlockLock, Aluminium
Seat
Saddle
Prologo, Proxim W450
Seatpost
SRAM, Reverb AXS, Aluminium, Telescope, 31.6 mm
Motor & Battery
Motor
Yamaha, PW-X2, 250W, 80 Nm, 25 km/h
Battery
Yamaha, 600 Wh
Remote
Yamaha, Side Switch, 1.7" LCD, 7 functions
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.493 mm | 1.388 mm | 1.352 mm | 1.268 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 736 mm | 766 mm | 799 mm | 829 mm |
| Rake | 60 mm | 60 mm | 60 mm | 60 mm |
| Trail | 108 mm | 108 mm | 108 mm | 108 mm |
| Stack | 597 mm | 597 mm | 615 mm | 615 mm |
| Reach | 400 mm | 430 mm | 455 mm | 485 mm |
| Top Tube Length | 560 mm | 590 mm | 620 mm | 650 |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 130 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1195 mm | 1225 mm | 1258 mm | 1288 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
AllMtn SE completes the Haibike E Allmtn model. 24 e-bikes variations carry this model name so far. You can easily view all of the Haibike E Allmtn e-bikes models from 2021, here.
Model range prices
Haibike AllMtn 2 2021 is the cheapest e-bike model and costs 4777$. Haibike AllMtn SE 2021 is the most expensive one and costs 10618$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro e-bikes average price
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2021 for 10618$. Comparing the average cost of an Enduro e-bike to this one, you will see that AllMtn SE price is 121.9% more expensive.
Overview of components
Fork
Haibike AllMtn SE 2021 e-bike is equipped with the Öhlins RXF36 fork, and has 160mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When leaving the production line, the AllMtn SE model has 29″ carbon wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The AllMtn SE has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the AllMtn SE. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
