Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset Alivio -
Suspension Hardtail -
Motor Bosch 250W 65Nm mid-drive -
Battery Bosch, PowerTube, 500 Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, HardNine Gen3 Intube, Aluminium 6061
Suspension Fork
SR Suntour, XCM32 Boost DS, Steel spring/oil, Travel= 120 mm, Aluschaft 1 1/8 - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Drivetrain
Rear Derailleur
Shimano, Alivio M3100
Shift Levers
Shimano, Alivio M3100, Trigger switch, 9 Speed
Cassette
Shimano, HG200, 11 - 36 teeth
Crank
Steel, 38 teeth
Bottom Bracket
Integrated in the motor
Chain
KMC, e9S
Pedals
Freeridepedal, Aluminium, with Reflector,
Wheels
Rims
Schürmann, Yak25, with eyelets, hollow rim, Aluminium
Spokes
Sapim, Leader, Black
Tires
WTB, Ranger Comp, 55-622, 29" x 2.30"
Brakes
Brakes
hydraulicDisc
Brake Levers
Tektro, M275, Aluminium
Cockpit
Stem
XLC, Alu, A-head
Handlebar
XLC, Topflat, 720 mm
Grips
Haibike, MTB grips
Headset
Feimin, A-Head Tapered, Ball bearing
Seat
Saddle
XLC, MTB
Seatpost
XLC, Aluminium, Patent, 31.6 mm
Motor & Battery
Motor
Bosch, Performance Line, 250W, 65 Nm, 25 km/h
Battery
Bosch, PowerTube, 500 Wh
Remote
Bosch, Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 305 mm | 310 mm | 310 mm |
| Front Center | 762 mm | 799 mm | 835 mm |
| Rake | 56 mm | 55 mm | 54 mm |
| Trail | 113 mm | 114 mm | 115 mm |
| Stack | 640 mm | 653 mm | 676 mm |
| Reach | 419 mm | 449 mm | 475 mm |
| Top Tube Length | 598 mm | 631 mm | 663 mm |
| Seat Tube Angle | 74.6 ° | 74.6 ° | 74.6 ° |
| Seat Tube Length | 460 mm | 490 mm | 510 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 115 mm | 135 mm | 160 mm |
| Chainstay Length | 487 mm | 487 mm | 487 mm |
| Wheelbase | 1241 mm | 1279 mm | 1315 mm |
| Bottom Bracket Drop | 69 mm | 64 mm | 64 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
HardNine 5 belongs to the Haibike E Hardnine model. 8 e-bikes variations carry this model name so far. You can easily view all of the Haibike E Hardnine e-bikes models from 2021, here.
Model range prices
Haibike HardNine 4 2021 is the cheapest e-bike model and costs 2760$. Haibike HardNine 10 2021 is the most expensive one and costs 4565$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
At the moment of the release date, Haibike HardNine 5 price was 2972$. Comparing the average cost of a Trail e-bike to this one, you will see that HardNine 5 price is 13.22% lower.
Overview of components
Fork
The HardNine 5 comes factory-installed with the Suntour XCM fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this e-bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
The HardNine 5 2021 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The HardNine 5 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
