Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset Acera, Shimano -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, Seet 2021, Aluminium 6061
Suspension Fork
SR Suntour, XCT HLO-DS, Lockout, Steel spring, Travel= 100 mm, Steel steerer tube 1 1/8", Quick release 100mm
Drivetrain
Rear Derailleur
Shimano, Acera M360
Shift Levers
Shimano, EF505, Shift / brake lever combination, 24 Speed
Cassette
SunRace, CSM40, 12 - 32 teeth
Crank
Shimano, TY301, Aluminium, 24 - 42 - 32 teeth
Bottom Bracket
FP-B908L, BSA, 122.5 mm
Chain
KMC, Z51
Pedals
Feimin, Plastic, FP-806B, Non-Slip
Wheels
Rims
XLC, X-630 D-WALL, hollow rim, Aluminium
Spokes
Black
Tires
Mitas, Ocelot, 54-584, 27.5" x 2.1", Mitas, Ocelot, 54-622, 29" x 2.1"
Brakes
Brakes
hydraulicDisc
Brake Levers
Shimano, EF505, Aluminium
Cockpit
Stem
XLC, Alu, A-head
Handlebar
XLC, Topflat, 720 mm
Grips
XLC, MTB grips
Headset
WTB, NO.10 ED 1-1/8" SEMI INTEGRATED, Aluminium
Seat
Saddle
XLC, MTB
Seatpost
Aluminium, Patent, 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.53 mm | 1.49 mm | 1.55 mm | 1.51 mm | 1.47 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 637 mm | 663 mm | 684 mm | 691 mm | 712 mm | 732 mm |
| Rake | 42 mm | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm |
| Trail | 98 mm | 98 mm | 98 mm | 94 mm | 94 mm | 94 mm |
| Stack | 582 mm | 592 mm | 601 mm | 624 mm | 633 mm | 642 mm |
| Reach | 365 mm | 387 mm | 404 mm | 402 mm | 420 mm | 437 mm |
| Top Tube Length | 539 mm | 564 mm | 584 mm | 589 mm | 609 mm | 629 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 360 mm | 400 mm | 440 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1057 mm | 1083 mm | 1104 mm | 1128 mm | 1149 mm | 1170 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 182 cm | 189 cm | 195 cm |
Model Overview
SEET 7 belongs to the Haibike Seet model. 31 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
The most economical model, the Haibike SEET Greedy 16” 2021 has a starting price of 264$. Haibike SEET 10 2021 on the other hand is the most expensive at 901$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 583$. Comparing the average cost of a Crosscountry bike to this one, you will see that SEET 7 price is 226.76% lower.
Overview of components
Fork
The fork installed on this bike is the Suntour XCT model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
When it comes to wheels, the SEET 7 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Haibike SEET 7 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Haibike SEET 7 bike has 6 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
