Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Deore, Acera -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, Seet HardNine, Aluminium 6061, Disc brake Post Mount
Suspension Fork
SR Suntour, XCT HLO-DS, Lockout, Steel spring, Travel= 100 mm, Steel steerer tube 1 1/8", Quick release 100mm
Drivetrain
Rear Derailleur
Shimano, Deore M592
Shift Levers
Shimano, Acera M3000, Rapidfire, 27 speed
Cassette
Shimano, HG201, 11 - 34 teeth
Crank
Shimano, MT210-3, 22 - 30 - 40 teeth
Bottom Bracket
Shimano, BB52
Chain
KMC, X9
Pedals
VP, VPE-993, Plastic, with Reflector
Wheels
Rims
XLC, X-630 D-WALL, hollow rim, Aluminium
Spokes
black
Tires
XLC, MountainX, 54-622, 29" x 2.10"
Brakes
Brake Levers
Tektro, M275, Aluminium
Cockpit
Stem
Haibike Components, TheStem +, A-head, Bar bore: 31.8 mm, 7°
Handlebar
Haibike Components, TheBar + Topflat, 720 mm
Grips
Haibike, MTB grips
Headset
Feimin, A-Head Tapered, ball bearing
Seat
Saddle
Haibike Components, TheSaddle
Seatpost
Haibike Components, The seat post ++, Patent, 31.6 mm, Aluminium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.559 mm | 1.516 mm | 1.494 mm | 1.489 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 653 mm | 674 mm | 689 mm | 705 mm |
| Rake | 47 mm | 46 mm | 46 mm | 46 mm |
| Trail | 86 mm | 87 mm | 87 mm | 87 mm |
| Stack | 619 mm | 629 mm | 638 mm | 652 mm |
| Reach | 397 mm | 415 mm | 427 mm | 438 mm |
| Top Tube Length | 575 mm | 595 mm | 610 mm | 625 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 140 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1086 mm | 1107 mm | 1122 mm | 1138 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 790 mm | 800 mm | 830 mm | 860 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
SEET HardNine 4.0 is a Haibike Seet model. There are 31 bikes that carry this model name. Take a sneak peek at all Haibike Seet bikes models from 2020, by clicking here.
Model range prices
Haibike SEET Greedy 16” 2020 is the cheapest bike model and costs 264$. Haibike SEET HardNine 6.0 2020 is the most expensive one and costs 1061$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 742$. Comparing this to the average Crosscountry bike price, we see that the price is 156.74% lower.
SEET HardNine 4.0 components
Fork
The fork installed on this bike is the SunTour XCT model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
As for the wheels, Haibike SEET HardNine 4.0 2020, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The SEET HardNine 4.0 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
