Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCR Air
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, Seet HardNine, Aluminium 6061, Disc brake Post Mount
Suspension Fork
SR Suntour, XCR Air RL-R, Remote Lockout, Air, Travel= 100 mm, Steel steerer tube 1 1/8", Quick release 100mm
Drivetrain
Rear Derailleur
Shimano, Deore M6000
Shift Levers
Shimano, Deore M6000, Rapidfire, 30 speed
Cassette
Shimano, HG5010, 11 - 36 teeth
Crank
Shimano, Deore M6000, 22 - 30 - 40 teeth
Bottom Bracket
Shimano, BB52
Chain
KMC, X10
Pedals
VP, VPE-993, Plastic, with Reflector
Wheels
Rims
XLC, X-630 D-WALL, hollow rim, Aluminium
Spokes
black
Tires
Schwalbe, Rapid Rob, 57-622, 29" x 2.25"
Brakes
Brake Levers
Tektro, M275, Aluminium
Cockpit
Stem
Haibike Components, TheStem +, A-head, Bar bore: 31.8 mm, 7°
Handlebar
Haibike Components, TheBar + Topflat, 720 mm
Grips
Haibike, MTB grips
Headset
Feimin, A-Head Tapered, ball bearing
Seat
Saddle
Haibike Components, TheSaddle
Seatpost
Haibike Components, The seat post ++, Patent, 31.6 mm, Aluminium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.559 mm | 1.516 mm | 1.494 mm | 1.489 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 653 mm | 674 mm | 689 mm | 705 mm |
| Rake | 47 mm | 46 mm | 46 mm | 46 mm |
| Trail | 86 mm | 87 mm | 87 mm | 87 mm |
| Stack | 619 mm | 629 mm | 638 mm | 652 mm |
| Reach | 397 mm | 415 mm | 427 mm | 438 mm |
| Top Tube Length | 575 mm | 595 mm | 610 mm | 625 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 140 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1086 mm | 1107 mm | 1122 mm | 1138 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 790 mm | 800 mm | 830 mm | 860 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
SEET HardNine 5.0 is part of the Haibike Seet model. Haibike released 31 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
The most economical model, the Haibike SEET Greedy 16” 2020 has a starting price of 264$. Haibike SEET HardNine 6.0 2020 on the other hand is the most expensive at 1061$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 848$. If we compare this with the average Crosscountry bike cost we notice that the price is 124.65% smaller.
SEET HardNine 5.0 components
Fork
Haibike SEET HardNine 5.0 2020 bike is equipped with the SunTour XCR Air fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
SEET HardNine 5.0 has a steel fork, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
When it comes to wheels, the SEET HardNine 5.0 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Haibike SEET HardNine 5.0 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
