Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Travel Front 100mm -
Fork Suntour MOBIE
-
Groupset NX -
Suspension Hardtail -
Motor Yamaha 250W 75Nm mid-drive -
Battery InTube, 720 Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
SR Suntour, Mobie 25 LOR, Lockout, Steel spring, travel= 100 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 100mm thru-axle
Drivetrain
Rear Derailleur
SRAM, NX
Shift Levers
SRAM, NX
Cassette
SRAM, PG1130
Crank
Steel, 38 teeth
Bottom Bracket
integrated in the motor
Chain
SRAM, NX
Chain Guide
Nylon directmount
Pedals
VP, E461, Aluminium, with Reflector
Wheels
Rims
Schürmann, Yak25, with eyelets, hollow rim, Aluminium
Spokes
Sapim, Leader, Black
Tires
Continental, Ruban Reflex, 27.5" x 2.3"
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano, MT402, Aluminium,
Cockpit
Stem
XLC, A-Head verstellbar, A-head, 31.8 mm
Handlebar
Ergoriser, oversize, 720 mm
Headset
Feimin, A-Head Tapered, Aluminium, Cartridge
Seat
Saddle
Selle Royal, Essenza
Seatpost
Aluminium, Patent, 34.9 mm
Motor & Battery
Motor
Yamaha, PW-S2, 250W, 75 Nm
Battery
InTube, 720 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.555 mm | 1.519 mm | 1.512 mm | 1.481 mm | 1.441 mm |
| Front Center | 712 mm | 722 mm | 739 mm | 764 mm | 787 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 45 mm |
| Trail | 86 mm | 86 mm | 86 mm | 86 mm | 85 mm |
| Stack | 656 mm | 656 mm | 670 mm | 684 mm | 693 mm |
| Reach | 422 mm | 432 mm | 443 mm | 462 mm | 481 mm |
| Top Tube Length | 610 mm | 620 mm | 635 mm | 658 mm | 680 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 140 mm | 140 mm | 155 mm | 170 mm | 180 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1171 mm | 1181 mm | 1198 mm | 1223 mm | 1246 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
About this model
Trekking 5 belongs to the Haibike E Trekking model. Haibike released 68 e-bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the Haibike Trekking 3 MID 2023 has a starting price of 3397$. Haibike Trekking 11 HIGH 2023 on the other hand is the most expensive at 5520$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid e-bikes average price
According to our calculations, the average cost of a Hybrid e-bike that is reliable is 2480$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 4034$. Comparing this to the average Hybrid e-bike price, we see that the price is 62.66% more expensive.
Trekking 5 components
Fork
Haibike Trekking 5 2023 e-bike is equipped with the Suntour MOBIE fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
When it comes to the fork, this e-bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
As for the wheels, Haibike Trekking 5 2023, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Trekking 5 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
