Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset GX Eagle, SX Eagle -
Suspension Hardtail -
Motor Yamaha 250W 85Nm mid-drive -
Battery InTube, 720 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
RockShox, Recon RL, Remote Lockout, Air, travel= 100 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 100mm thru-axle
Drivetrain
Rear Derailleur
SRAM, GX Eagle
Shift Levers
SRAM, SX Eagle
Cassette
SRAM, Eagle PG1210, 11 - 50 teeth
Crank
SRAM, X Sync II Eagle, 38 teeth
Bottom Bracket
integrated in the motor
Chain
SRAM, SX Eagle
Chain Guide
0.0
Pedals
VP, E461, Aluminium, with Reflector
Wheels
Rims
Schürmann, Yak25, with eyelets, hollow rim, Aluminium
Spokes
Sapim, Leader, Black
Tires
Schwalbe, Johnny Watts, 60-584, 27.5" x 2.35"
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano, MT401, Aluminium,
Cockpit
Stem
XLC, A-Head verstellbar, A-head, 31.8 mm
Handlebar
Ergoriser, oversize, 720 mm
Headset
Feimin, A-Head Tapered, Aluminium, Cartridge
Seat
Saddle
Selle Royal, Essenza
Seatpost
Seat- Post, Aluminium, 34.9 mm
Motor & Battery
Motor
Yamaha, PW-X3, 250W, 85 Nm
Battery
InTube, 720 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.555 mm | 1.519 mm | 1.512 mm | 1.481 mm | 1.441 mm |
| Front Center | 712 mm | 722 mm | 739 mm | 764 mm | 787 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 45 mm |
| Trail | 86 mm | 86 mm | 86 mm | 86 mm | 85 mm |
| Stack | 656 mm | 656 mm | 670 mm | 684 mm | 693 mm |
| Reach | 422 mm | 432 mm | 443 mm | 462 mm | 481 mm |
| Top Tube Length | 610 mm | 620 mm | 635 mm | 658 mm | 680 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 140 mm | 140 mm | 155 mm | 170 mm | 180 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1171 mm | 1181 mm | 1198 mm | 1223 mm | 1246 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
Model Overview
Trekking 7 is a Haibike E Trekking model. 68 e-bikes variations carry this model name so far. You can easily view all of the Haibike E Trekking e-bikes models from 2023, here.
Model range prices
The most economical model, the Haibike Trekking 3 MID 2023 has a starting price of 3397$. Haibike Trekking 11 HIGH 2023 on the other hand is the most expensive at 5520$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid e-bikes average price
If you want to purchase a solid Hybrid e-bike, it is important to know that the average cost is 2480$. However, this doesn’t mean that if you spend less money on a Hybrid e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4671$. Comparing this to the average Hybrid e-bike price, we see that the price is 88.35% higher.
Trekking 7 components
Fork
The Trekking 7 comes factory-installed with the RockShox Recon Silver RL fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the Trekking 7 model has aluminum wheels. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Haibike Trekking 7 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
