Haibike XDURO AllMtn 8.0 2020
2020 E-bike
Estimate price |
8,028$
Weight | 27.7 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Performance Elite Float 36
-
Groupset XT -
Suspension Full -
Motor 120Nm mid-drive -
Battery Flyon, The Battery, 630 Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, XDURO AllMtn, Carbon/aluminium, Thru-axle M12 (1.75) x 148mm, Disc brake Post Mount, Travel= 150 mm
Suspension Fork
FOX, 36 Float Performance Elite, Lockout, Air, Travel= 150 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Drivetrain
Rear Derailleur
Shimano, Deore XT M8000
Shift Levers
Shimano, Deore XT M8000, Rapidfire, 11 speed
Cassette
Shimano, SLX M7000, 11 - 46 teeth
Crank
Haibike Components, Aluminium, 38 teeth
Bottom Bracket
integrated in the motor
Chain
Shimano, HG601
Pedals
Feimin, MTB platform pedal, Aluminium
Wheels
Rims
Rodi, Tryp 30, with eyelets, hollow rim, Aluminium
Spokes
DT Swiss, Industry, black
Tires
Maxxis, Minion DHF, 63-622, 29" x 2.50"
Brakes
Brake Levers
Shimano, Deore XT M8000, Aluminium
Cockpit
Stem
Haibike Components, TheStem 2, A-head, Bar bore: 31.8 mm
Handlebar
Haibike Components, The Bar +++, 780 mm
Grips
Haibike, MTB grips
Headset
Feimin, A-Head Tapered, Aluminium, cartridge bearing
Seat
Saddle
Haibike Components, TheSaddle
Seatpost
XLC, AllMtn, Remote, Telescope, 34.9 mm, Aluminium
Motor & Battery
Motor
Flyon, HPR120S, 25 km/h, 120 Nm
Battery
Flyon, The Battery, 630 Wh
Remote
Flyon, The Display
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.565 mm | 1.456 mm | 1.416 mm | 1.329 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 727 mm | 757 mm | 790 mm | 820 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 121 mm | 121 mm | 121 mm | 121 mm |
| Stack | 629 mm | 629 mm | 647 mm | 647 mm |
| Reach | 402 mm | 432 mm | 457 mm | 487 mm |
| Top Tube Length | 570 mm | 600 mm | 630 mm | 660 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 130 mm |
| Chainstay Length | 470 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 1196 mm | 1226 mm | 1259 mm | 1289 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 840 mm | 830 mm | 850 mm | 860 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
XDURO AllMtn 8.0 completes the Haibike E Xduro model. Haibike released 44 e-bikes variations of this model so far. Take a sneak peek at all Haibike E Xduro e-bikes models from 2020, by clicking here.
Model range prices
Haibike XDURO FatSix 8.0 2020 is the most affordable e-bike of this model and has a price of 3715$. On the other hand, Haibike XDURO AllMtn 10.0 2020, is the most expensive and costs 9555$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro e-bikes average price
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2020 and its price was 7431$. Comparing the average cost of an Enduro e-bike to this one, you will see that XDURO AllMtn 8.0 price is 55.3% higher.
Average weight for Enduro e-bikes
On a deeper look, we notice that the average weight of an Enduro e-bike is 23.42 kg (51.63 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 27.7 kg (61.07 lbs), Haibike e-bike is much heavier than average. In conclusion, the average Enduro e-bike weighs 18.27% less than XDURO AllMtn 8.0.
Overview of components
Fork
Haibike XDURO AllMtn 8.0 2020 e-bike is equipped with the Fox Performance Elite Float 36 fork, and has 150mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
When it comes to the fork, this e-bike has an aluminum one, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Rear Shock
Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The XDURO AllMtn 8.0 2020 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Haibike XDURO AllMtn 8.0 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Haibike XDURO AllMtn 8.0 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
