Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Fork SunTour XCT -
Groupset Acera, Alivio -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haro Double Peak 29.0" 6000 series alloy, w/ Internal housing routing & chainstay disc brake mount
Suspension Fork
New SR Suntour XCT-30 29x100mm travel w/ hydraulic lockout
Drivetrain
Rear Derailleur
Shimano Acera 9-spd RD-M3000
Front Derailleur
Shimano Alivio, FD-M4020-M, 2x9-spd, Top Swing
Shift Levers
Shimano Acera M3010, 2x9-spd
Cassette
Shimano HG-200 9-spd 11-36T
Crank
Suntour XCD-D114, 34/24T, 2X9-Spd
Bottom Bracket
SR BB10-XCT Sealed cartridge
Chain
KMC Z9 9-spd
Pedals
New FPD Nylon body, Crmo axles,Platform
Wheels
Front Hub
New Shimano TX-505 alloy, Center Lock Disc, cassette 32h
Rear Hub
New Shimano TX-505 alloy, Center Lock Disc, cassette 32h
Rims
Weinmann U-26 Disc alloy double wall
Tires
Kenda Honey Badger XC 29.0*2.2
Brakes
Brakes
Shimano BR-MT200 hydraulic, 160mm Center Lock Rotors
Brake Levers
Shimano BL-MT200
Cockpit
Stem
Pivit forged stem, 31.8mm
Handlebar
Pivit alloy 15mm riser bar 31.8mm
Headset
1-1/8" Threadless for 50mm OD headtube; w/ 13mm top cover
Seat
Saddle
New Haro Double Peak
Seatpost
Pivit alloy micro adjust 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.53 mm | 1.54 mm | 1.54 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 649 mm | 660 mm | 669 mm | 679 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 84 mm | 80 mm | 79 mm | 80 mm |
| Stack | 633 mm | 635 mm | 645 mm | 654 mm |
| Reach | 398 mm | 414 mm | 419 mm | 426 mm |
| Top Tube Length | 597 mm | 614 mm | 622 mm | 632 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 419 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1093 mm | 1104 mm | 1113 mm | 1123 mm |
| Bottom Bracket Drop | 64 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 752 mm | 756 mm | 777 mm | 800 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Double Peak 29 Trail completes the Haro Double model. There are 23 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Haro Double Peak 29 Sport 2019 is the most economical model, with a starting price of 599$. Haro Double Peak 27.5 Plus Comp 2019 on the other hand costs 979$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2019 and its price was 699$. Doing a quick comparison, we notice that Double Peak 29 Trail price is 172.53% smaller than the average cost of a Crosscountry bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The Double Peak 29 Trail comes factory-installed with the SunTour XCT fork. This has a travel range of mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on Double Peak 29 Trail are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
