Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Fork SunTour XCT -
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New 2021 Haro Double Peak 29" X6 Aluminum series | Tapered head tube | Internal housing routing | Chainstay disc brake mount | 73mm threaded BSA
Suspension Fork
SR Suntour XCT-30 | 29x100mm travel | Hydraulic lockout
Drivetrain
Rear Derailleur
New Alivio M3100 SGS 9-spd | Shadow design
Front Derailleur
Shimano Altus | FD-M2020 | 2x9-spd | Top Swing
Shift Levers
New Shimano SL-M2010-2L | 2x9-spd
Cassette
Shimano HG-200 9-spd 11-36T
Crank
Shimano MT-101 | 36/22T | 2x9-Spd
Bottom Bracket
Shimano Sealed cartridge
Chain
KMC Z9 9-spd
Pedals
FPD Nylon body | Chromoly axles | Platform
Wheels
Front Hub
Shimano TX-505 alloy | Center Lock Disc | cassette 32h
Rear Hub
Shimano TX-505 alloy | Center Lock Disc | cassette 32h
Rims
MX-21 29"x27mm Aluminum double wall
Tires
Kenda Honey Badger XC 29.0*2.2
Brakes
Brakes
Shimano BR-MT200 hydraulic | 160mm Center Lock Rotors
Brake Levers
Shimano BL-MT200
Cockpit
Stem
Pivit forged stem
Handlebar
Pivit aluminum | 15mm riser bar | 31.8mm
Headset
1-1/8"-1.5" Threadless for 50/62mm OD headtube | 10.0mm Aluminum top cover
Seat
Saddle
New Haro Double Peak
Seatpost
Pivit aluminum micro adjust 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.39 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 722 mm | 747 mm | 769 mm | 788 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 632 mm | 632 mm | 636 mm | 646 mm |
| Reach | 431 mm | 456 mm | 476 mm | 491 mm |
| Top Tube Length | 599 mm | 624 mm | 645 mm | 663 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 406 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 100 mm | 105 mm | 115 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1171 mm | 1196 mm | 1218 mm | 1237 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 744 mm | 747 mm | 757 mm | 780 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Double Peak 29 Trail belongs to the Haro Double model. 23 bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Haro Double Peak 27.5 Sport 2021 is the cheapest bike model and costs 699$. Haro Double Peak 27.5 Comp 2021 is the most expensive one and costs 1199$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 799$. Comparing the average cost of a Crosscountry bike to this one, you will see that Double Peak 29 Trail price is 138.42% lower.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Double Peak 29 Trail components
Fork
This bike has the SunTour XCT fork installed. The fork’s travel is mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Double Peak 29 Trail model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Haro Double Peak 29 Trail bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
