Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork SunTour XCR 34
-
Groupset Deore, Suntour -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New MY20 X6 series alloy dual suspended 4-Bar linkage frame, 120mm rear travel, tapered 1.5" head tube, 73mm BB shell, Enduro bearings, Boost 12mm thru-axle dropouts
Suspension Fork
XCR-34 Air, Boost, 27.5", Steel stanchions, 1.5" tapered alloy steerer, 130mm travel, w/ hydraulic lockout, w/ Thru-Axle
Rear Shock
X-Fusion 02 Pro R, Trunnion, 165x42.5mm w/ Rebound adjuster
Drivetrain
Rear Derailleur
New Shimano Deore RD-M5100, 11-spd, Top Normal, Shadow Plus design
Shift Levers
New Shimano Deore M5100, right only, 1x11-spd, w/ optical gear display
Cassette
New Shimano Deore CS-M5100 11-spd 11-51T
Crank
Suntour Zeron 1X AX-S-BT-30, Boost, 30T Steel Zig-Zag Chainring
Bottom Bracket
Suntour BB-BKA008-C, 73mm, sealed cartridge
Chain
KMC X11 NP/GY, w/ Missing Link
Pedals
N/A
Wheels
Front Hub
Shimano MT400-B, Boost Disc alloy 32h, 15x110mm Frt & 12x148mm Rear Thru-Axles
Rear Hub
Shimano MT400-B, Boost Disc alloy 32h, 15x110mm Frt & 12x148mm Rear Thru-Axles
Rims
Weinmann U-28 Disc 27.5" x 32h alloy double wall
Tires
Kenda Regolith, 27.5x2.4"
Brakes
Brakes
Shimano hydraulic BR-MT200 180/160mm Center Lock rotors
Brake Levers
Shimano BL-MT201 hydraulic
Cockpit
Stem
Pivit alloy Trail 0 Deg. 4 bolts, ext.: 40mm
Handlebar
Pivit alloy 20mm riser bar 31.8mm, 760mm, 9 Deg. sweep
Headset
FPD DOZER-1160A-2 w/ 1.5" ACB bottom for 44/56mm head tube, W/ 8mm Top Cone
Seat
Saddle
WTB Volt Sport w/ color accents
Seatpost
Pivit alloy micro adjust 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.33 mm | 1.28 mm | 1.23 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 712 mm | 742 mm | 770 mm | 794 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 105 mm | 104 mm | 105 mm | 110 mm |
| Stack | 583 mm | 593 mm | 602 mm | 611 mm |
| Reach | 421 mm | 446 mm | 471 mm | 496 mm |
| Top Tube Length | 581 mm | 609 mm | 638 mm | 666 mm |
| Seat Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Seat Tube Length | 396 mm | 433 mm | 471 mm | 496 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1137 mm | 1167 mm | 1195 mm | 1219 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Shift R5 27.5 completes the Haro Shift model. 31 bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Haro Shift S3 27.5 2020 is the most economical model, with a starting price of 1399$. Haro Shift R9 27.5 2020 on the other hand costs 3249$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1749$. If we compare this with the average Trail bike cost we notice that the price is 57.92% lower.
Shift R5 27.5 components
Fork
Haro Shift R5 27.5 2020 bike is equipped with the SunTour XCR 34 fork, and has 130mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
Haro Shift R5 27.5 bike has the X-Fusion 02 Pro R model installed, and has a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the Shift R5 27.5 model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
