Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haro full Crmo Steel Reserve frame w/ internal head tube & Euro BB shell
Suspension Fork
Suspension Corrected Rigid Chromoly w/ Disc Brake Tabs
Rear Shock
N/A
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
12T Crmo Cog
Crank
Haro Crmo 8 Spline 3-pc 25t
Bottom Bracket
4 x Sealed bearing
Chain
KMC HV410 1/2" X 1/8"
Chain Guide
None
Pedals
Wellgo Platform alloy w/ Replaceable Pins
Wheels
Front Hub
Pivit alloy disc singlespeed cassette 36h
Rear Hub
Pivit alloy disc singlespeed cassette 36h
Rims
Weinmann XM260 alloy double wall
Spokes
Stainless steel
Tires
Kenda K-Rad 26 x 2.3"
Brakes
Brakes
Tektro Aries MD-M280
Brake Levers
Tektro ML-330
Cockpit
Stem
Haro front load alloy 1-1/8"
Handlebar
Haro Steel 65mm riser bar, 730mm wide, 6 Deg. back sweep
Grips
Haro Counterfeit
Headset
VP-A46ACM, 1-1/8" Alloy, 45°X45° Semi-Cartridge Bearings
Seat
Saddle
Haro Padded Slim one piece seat/post
Seatpost
Alloy 25.4mm included w/ seat
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Short | Long |
|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.36 mm |
| Bottom Bracket Height | 325 mm | 325 mm |
| Front Center | 624 mm | 642 mm |
| Rake | 40 mm | 40 mm |
| Trail | 89 mm | 90 mm |
| Stack | 546 mm | 546 mm |
| Reach | 383 mm | 402 mm |
| Top Tube Length | 559 mm | 575 mm |
| Seat Tube Angle | 70 ° | 70 ° |
| Seat Tube Length | 285 mm | 285 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 117 mm | 117 mm |
| Chainstay Length | 393 mm | 393 mm |
| Wheelbase | 1016 mm | 1034 mm |
| Bottom Bracket Drop | 17 mm | 17 mm |
| Standover Height | 674 mm | 668 mm |
| Wheels | 26" | 26" |
Model Overview
Steel Reserve 1.1 is part of the Haro Steel model. There are 12 bikes that carry this model name. You can easily view all of the Haro Steel bikes models from 2019, here.
Model range prices
Haro Steel Reserve 1.1 2019 is the most affordable bike of this model and has a price of 599$. On the other hand, Haro Steel Reserve 1.2 2019, is the most expensive and costs 929$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Dirt Jump bikes average price
Our math shows that the average cost of a dependable Dirt Jump bike is 863$. However, this doesn’t mean that if you spend less money on a Dirt Jump bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Haro released this model in 2019, its price was 599$. In conclusion, this bike price is 44.07% lower than the price of the average Dirt Jump bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Steel Reserve 1.1 components
Fork material
When it comes to the fork, this bike has a steel one, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
As for the wheels, Haro Steel Reserve 1.1 2019, has a 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
