Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 65mm -
Fork Zoom
-
Groupset Alivio, Altus -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery Darfon 504 Wh -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy 6061 HT, integrated battery
Suspension Fork
Zoom 187D AMS HLO 65mm
Drivetrain
Rear Derailleur
Shimano Alivio RDT4000 9 speed
Shift Levers
Shimano Altus SLM2010 1x9
Cassette
Sunshine MTB-CS-HR9-32 11-32
Crank
Shimano FCE5010 44/175mm
Pedals
Wellgo M272T DU
Wheels
Front Hub
Formula DC20 QR 100mm
Rear Hub
Formula DC22 QR 135mm
Rims
Remerx Dragon 719 32h
Tires
Impac SmartPac 28x1.75”
Brakes
Brakes
Clarks Clout 160/160mm
Cockpit
Stem
HBC 60/31.8mm
Handlebar
HBC 660/31.8mm
Headset
Neco 386E
Seat
Saddle
HBC VL-3389
Seatpost
HBC 350/27.2mm
Motor & Battery
Motor
Shimano STePS DUE5000
Battery
Darfon 504 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 55cm | 59cm |
|---|---|---|---|
| Front Center | 669 mm | 679 mm | 692 mm |
| Top Tube Length | 599 mm | 609 mm | 621 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 550 mm | 590 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 155 mm | 155 mm | 174 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1118 mm | 1128 mm | 1141 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm |
| Wheels | 700 | 700 | 700 |
About this model
E I-Peak II men is part of the Head E E model. There are 17 e-bikes that carry this model name. Take a sneak peek at all Head E E e-bikes models from 2022, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Hybrid e-bikes
According to our math, the average price for a trustworthy Hybrid e-bike is 2480$. However, this doesn’t mean that if you spend less money on a Hybrid e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Hybrid e-bikes
On a deeper look, we notice that the average weight of a Hybrid e-bike is 23.79 kg (52.45 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
E I-Peak II men weighs 21.5 kg (47.4 lbs) and is considerably lighter than the average. In short, the average Hybrid e-bike weight is 10.65% higher than this one.
Overview of components
Fork
This e-bike has the Zoom fork installed. The fork’s travel is 65mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, HEAD E I-Peak II men 2022, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
