Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy 6061 HT, TPR, DB
Suspension Fork
Alu 12x100mm TPR
Drivetrain
Rear Derailleur
Shimano GRX 812 11 speed
Shift Levers
Shimano GRX 600 1x11
Cassette
Sunshine MTB-CS-HR11-42 11-42
Crank
FSA Omega 42/175mm
Wheels
Front Hub
HBC Pro 12x100mm
Rear Hub
HBC Pro 12x142mm
Rims
GXR 32h
Tires
Schwalbe G-One 622-40
Brakes
Brakes
Shimano GRX 600 160/160mm
Cockpit
Stem
HBC 90-120/31.8mm
Handlebar
HBC 440/31.8mm
Headset
Neco H373M
Seat
Saddle
HBC VL-4470
Seatpost
HBC Pro 350/31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 54cm | 58cm | 61cm |
|---|---|---|---|---|
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 594 mm | 600 mm | 609 mm | 615 mm |
| Top Tube Length | 512 mm | 548 mm | 573 mm | 590 mm |
| Seat Tube Angle | 76 ° | 74 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 540 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° |
| Head Tube Length | 125 mm | 140 mm | 170 mm | 190 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1012 mm | 1018 mm | 1028 mm | 1034 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
Picton II belongs to the Head Picton model. There are 2 bikes that carry this model name. You can easily view all of the Head Picton bikes models from 2022, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Gravel bikes
If we make a quick analysis of the average weight of a Gravel bike, we get 8.13 kg (17.92 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
HEAD Picton II it’s weighing 10.2 kg (22.49 lbs). At this weight, is much heavier than average. In conclusion, the average Gravel bike weighs 25.46% less than Picton II.
Picton II components
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
The wheels on Picton II are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
