Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID Ultimate
-
Groupset XX1 Eagle, X01 Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon TPR
Suspension Fork
Rock Shox SID Ultimate 100mm+oneloc, TPR
Drivetrain
Rear Derailleur
SRAM XX1 Eagle 12 speed
Shift Levers
SRAM X01 Eagle 1x12
Cassette
SRAM XG1299 Eagle 10-52
Crank
SRAM Descendant Carbon DUB 34/175mm
Wheels
Front Hub
HBC Pro 15x110mm straight
Rear Hub
HBC Pro 12x148mm straight
Rims
RRX CB TL carbon 28h
Tires
Schwalbe Racing Ralph/Ray 29x2.25” Evo SnakeSkin TLE
Brakes
Brakes
SRAM Level Ultimate 160/160mm
Cockpit
Stem
FSA SL-K carbon 70-90/31.8mm
Handlebar
FSA SL-K carbon 740/31.8mm
Headset
FSA Orbit C-40
Seat
Saddle
Prologo Kappa RS
Seatpost
FSA Carbon 350-400/31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 43cm | 48cm | 53cm |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.49 mm | 1.45 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm |
| Front Center | 655 mm | 675 mm | 689 mm |
| Rake | 57 mm | 57 mm | 51 mm |
| Trail | 69 mm | 69 mm | 75 mm |
| Stack | 612 mm | 622 mm | 631 mm |
| Reach | 400 mm | 417 mm | 434 mm |
| Top Tube Length | 588 mm | 608 mm | 628 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 432 mm | 482 mm | 532 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1083 mm | 1104 mm | 1118 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm |
| Wheels | 29" | 29" | 29" |
About this model
Trenton V belongs to the Head Trenton model. There are 12 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Trenton V weighs 9.4 kg (20.72 lbs) and is much lighter than the average. In short, the average Crosscountry bike weight is 31.91% higher than this one.
Overview of components
Fork
The Trenton V comes factory-installed with the RockShox SID Ultimate fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, HEAD Trenton V 2022, has a 29″ carbon model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Trenton V comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
