hercules E-Imperial Max I-F5 2023
2023 E-bike
Estimate price |
6,281$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour MOBIE
-
Groupset Shimano, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube (Smart System) 750 -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
SR SUNTOUR MOBIE E-25, 63 mm travel, air suspension, lockout, 15 mm thru axle
Drivetrain
Shift Levers
SHIMANO Revoshifter
Cassette
GATES CDX 30T
Crank
FSA CK-220
Wheels
Front Hub
SHIMANO HB-MT410, 15X100 mm, center lock
Rear Hub
SHIMANO HB-MT410, 15X100 mm, center lock
Rims
Ryde Andra 40
Tires
SCHWALBE Marathon E-Plus, SmartGuard, Performance, 55-622
Brakes
Brakes
SHIMANO BL-MT401
Cockpit
Stem
ZECURE UP2+, A-head, adjustable
Handlebar
Trekking, AL, 31.8 mm, 15° backsweep
Seat
Saddle
Selle Bassano Suprema 3Zone City
Seatpost
BySchulz G2, 350 mm, Ø31.6 mm, 30 mm travel
Motor & Battery
Motor
Bosch Performance Line CX (Smart System) 25/85Nm
Battery
Bosch PowerTube (Smart System) 750
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 49cm | 53cm | 57cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.49 mm | 1.51 mm | 1.51 mm |
| Front Center | 680 mm | 680 mm | 682 mm | 696 mm |
| Rake | 39 mm | 39 mm | 36 mm | 39 mm |
| Trail | 92 mm | 92 mm | 95 mm | 92 mm |
| Stack | 624 mm | 624 mm | 633 mm | 643 mm |
| Reach | 418 mm | 418 mm | 420 mm | 427 mm |
| Top Tube Length | 609 mm | 609 mm | 614 mm | 624 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 490 mm | 530 mm | 570 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Chainstay Length | 480 mm | 480 mm | 480 mm | 480 mm |
| Wheelbase | 1154 mm | 1154 mm | 1156 mm | 1170 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
E-Imperial Max I-F5 belongs to the Hercules E E Imperial model. Hercules released 3 e-bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Hercules E-Imperial Max I-12 2023 is the cheapest e-bike model and costs 5520$. Hercules E-Imperial Max I-F360+ 2023 is the most expensive one and costs 6370$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Hybrid e-bikes
If you want to purchase a solid Hybrid e-bike, it is important to know that the average cost is 2480$. However, even though the average price of a Hybrid e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
When Hercules released this model in 2023, its price was 5733$. In conclusion, this e-bike price is 131.17% higher than the price of the average Hybrid e-bike.
Overview of components
Fork
This e-bike has the Suntour MOBIE fork installed. The fork’s travel is 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on E-Imperial Max I-F5 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The E-Imperial Max I-F5 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
