Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Suntour Zeron
-
Groupset Deore -
Suspension Hardtail -
Motor Shimano 85Nm mid-drive -
Battery Simplo Intube 630 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
SR SUNTOUR Zeron 35, 120 mm travel, air suspension, lockout, 15 mm thru axle
Drivetrain
Rear Derailleur
SHIMANO Deore RD-M5120
Shift Levers
SHIMANO Deore SL-M4100
Cassette
Sunrace, CSMS2 TAZ 11-46T
Crank
HERCULES EC40
Chain
SHIMANO CN-HG54
Wheels
Front Hub
SHIMANO HB-MT410-B, 15X110 mm, center lock
Rear Hub
SHIMANO HB-MT410-B, 15X110 mm, center lock
Rims
RODI TRYP30
Tires
SCHWALBE Nobby Nic Performance, 65-584
Brakes
Brakes
SHIMANO MT420
Cockpit
Stem
A-Head, MonkeyLink ready
Handlebar
MTB riser, AL, 31.8 mm
Seat
Saddle
SELLE ROYAL Vivo
Seatpost
KALLOY SP-719, AL, 350 mm, Ø30.9 mm
Motor & Battery
Motor
SHIMANO Steps EP801 25/85Nm
Battery
Simplo Intube 630
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 48cm | 52cm |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.45 mm | 1.48 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm |
| Front Center | 706 mm | 730 mm | 754 mm |
| Rake | 49 mm | 49 mm | 50 mm |
| Trail | 91 mm | 91 mm | 90 mm |
| Stack | 647 mm | 647 mm | 676 mm |
| Reach | 421 mm | 446 mm | 458 mm |
| Top Tube Length | 623 mm | 648 mm | 669 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Chainstay Length | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1155 mm | 1180 mm | 1204 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 27" | 27" | 27" |
Model Overview
Nos 2.1 completes the Hercules E Nos model. 10 e-bikes variations carry this model name so far. You can easily view all of the Hercules E Nos e-bikes models from 2023, here.
Model range prices
Hercules Nos 1.1 2023 is the most affordable e-bike of this model and has a price of 3821$. On the other hand, Hercules Nos FS 2.1 2023, is the most expensive and costs 6582$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail e-bikes
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2023 and its price was 4671$. In conclusion, this e-bike price is 38.81% more expensive than the price of the average Trail e-bike.
Nos 2.1 components
Fork
Hercules Nos 2.1 2023 e-bike is equipped with the Suntour Zeron fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the Nos 2.1 e-bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Hercules Nos 2.1 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
