Ibis Hakka MX Frameset 2020
2020 Road
Estimate price |
1,999$
Weight | 1 kg
Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c / 650b -
Suspension Rigid -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber monocoque
Drivetrain
Bottom Bracket
T47 Threaded Bottom Bracket
Brakes
Brakes
Flat-mount front disc, 160mm rotor (some images show post mount)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 49cm | 53cm | 53cm | 55cm | 55cm | 58cm | 58cm | 61cm | 61cm |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.43 mm | 1.5 mm | 1.5 mm | 1.51 mm | 1.51 mm | 1.53 mm | 1.53 mm | 1.51 mm | 1.51 mm |
| Bottom Bracket Height | 279 mm | mm | 279 mm | mm | 279 mm | mm | 279 mm | mm | 279 mm | mm |
| Front Center | 587 mm | 587 mm | 591 mm | 591 mm | 601 mm | 601 mm | 617 mm | 617 mm | 637 mm | 637 mm |
| Rake | 46 mm | 46 mm | 47 mm | 47 mm | 42 mm | 42 mm | 42 mm | 42 mm | 47 mm | 47 mm |
| Trail | 75 mm | 68 mm | 67 mm | 61 mm | 72 mm | 66 mm | 72 mm | 66 mm | 64 mm | 58 mm |
| Stack | 536 mm | 536 mm | 564 mm | 564 mm | 584 mm | 584 mm | 603 mm | 603 mm | 620 mm | 620 mm |
| Reach | 374 mm | 374 mm | 377 mm | 377 mm | 386 mm | 386 mm | 395 mm | 395 mm | 410 mm | 410 mm |
| Top Tube Length | 524 mm | 524 mm | 544 mm | 544 mm | 554 mm | 554 mm | 574 mm | 574 mm | 594 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 455 mm | 525 mm | 525 mm | 550 mm | 550 mm | 575 mm | 575 mm | 605 mm | 605 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 110 mm | 135 mm | 135 mm | 155 mm | 155 mm | 175 mm | 175 mm | 195 mm | 195 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1011 mm | 1011 mm | 1015 mm | 1015 mm | 1025 mm | 1025 mm | 1041 mm | 1041 mm | 1061 mm | 1061 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 733 mm | 733 mm | 789 mm | 789 mm | 806 mm | 806 mm | 831 mm | 831 mm | 857 mm | 857 mm |
| Wheels | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 |
About this model
Hakka MX Frameset belongs to the Ibis Hakka model. 17 frames variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel frames
Our math shows that the average cost of a dependable Gravel frame is 1505$. However, you could also get a good Gravel frame even if you pay a lower amount than the average price. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
This frame was released in 2020 and its price was 1999$. Comparing the average cost of a Gravel frame to this one, you will see that Hakka MX Frameset price is 32.82% more expensive.
Average weight for Gravel frames
On a deeper look, we notice that the average weight of a Gravel frame is 2.06 kg (4.54 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 1 kg (2.2 lbs), the Hakka MX Frameset model is much lighter than average. In conclusion, the average Gravel frame weighs 106% more than Hakka MX Frameset.
Overview of components
Fork material
When it comes to the fork, this frame has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Brakes
Stopping the bike when needed, it’s essential for your safety. This frame has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
