Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c / 650b -
Groupset GRX 800, Praxis -
Suspension Rigid -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber monocoque
Suspension Fork
ENVE G Series Carbon Fiber Gravel Fork: Flat Mount, Fender Eyelets, Internal Routing, Through Axle
Drivetrain
Rear Derailleur
Shimano GRX RX812 Shadow Plus
Shift Levers
Shimano GRX R810
Cassette
Shimano XT 11-42
Crank
Praxis Zayante M30 Carbon, 30mm spindle, 40t Alloy Ring (170mm on 49cm, 172.5mm on 53, 55 and 58cm, 175mm on 61cm)
Bottom Bracket
T47 Threaded Bottom Bracket
Chain
Shimano HG-701
Wheels
Rims
Ibis 733 Aluminum (27.5"/650b) or Stan’s Grail (700c), Ibis Hubs
Tires
Schwalbe Thunder Burt 27.5" x 2.1" or Maxxis Rambler 700c x 40mm, EXO
Brakes
Brakes
Shimano GRX RX810
Disk Rotors
Shimano SM-RT86 160
Cockpit
Stem
Enve Road Stem (80mm, 90mm, 100mm)
Handlebar
Enve G Series Gravel Bar (42mm on 49cm and 53cm, 44mm on 55cm, 46mm on 58cm and 61cm)
Grips
Black EVA Bar Tape
Headset
Cane Creek 40 Headset, IS41/28.6 IS52/40
Seat
Saddle
WTB Silverado Team 142mm width
Seatpost
ENVE Carbon, 400mm length, 0mm offset, 31.6mm dia.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 49cm | 53cm | 53cm | 55cm | 55cm | 58cm | 58cm | 61cm | 61cm |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.43 mm | 1.5 mm | 1.5 mm | 1.51 mm | 1.51 mm | 1.53 mm | 1.53 mm | 1.51 mm | 1.51 mm |
| Bottom Bracket Height | 279 mm | mm | 279 mm | mm | 279 mm | mm | 279 mm | mm | 279 mm | mm |
| Front Center | 587 mm | 587 mm | 591 mm | 591 mm | 601 mm | 601 mm | 617 mm | 617 mm | 637 mm | 637 mm |
| Rake | 46 mm | 46 mm | 47 mm | 47 mm | 42 mm | 42 mm | 42 mm | 42 mm | 47 mm | 47 mm |
| Trail | 75 mm | 68 mm | 67 mm | 61 mm | 72 mm | 66 mm | 72 mm | 66 mm | 64 mm | 58 mm |
| Stack | 536 mm | 536 mm | 564 mm | 564 mm | 584 mm | 584 mm | 603 mm | 603 mm | 620 mm | 620 mm |
| Reach | 374 mm | 374 mm | 377 mm | 377 mm | 386 mm | 386 mm | 395 mm | 395 mm | 410 mm | 410 mm |
| Top Tube Length | 524 mm | 524 mm | 544 mm | 544 mm | 554 mm | 554 mm | 574 mm | 574 mm | 594 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 455 mm | 525 mm | 525 mm | 550 mm | 550 mm | 575 mm | 575 mm | 605 mm | 605 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 110 mm | 135 mm | 135 mm | 155 mm | 155 mm | 175 mm | 175 mm | 195 mm | 195 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1011 mm | 1011 mm | 1015 mm | 1015 mm | 1025 mm | 1025 mm | 1041 mm | 1041 mm | 1061 mm | 1061 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 733 mm | 733 mm | 789 mm | 789 mm | 806 mm | 806 mm | 831 mm | 831 mm | 857 mm | 857 mm |
| Wheels | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 |
About this model
Hakka MX GRX belongs to the Ibis Hakka model. Ibis released 17 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Ibis Hakka MX Rival 2020 is the cheapest bike model and costs 3399$. Ibis Hakka MX GRX 2020 is the most expensive one and costs 4399$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Ibis released this model in 2020, its price was 4399$. Comparing the average cost of a Gravel bike to this one, you will see that Hakka MX GRX price is 78.68% higher.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on Hakka MX GRX are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Hakka MX GRX has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
