Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c / 650b -
Groupset Rival, Praxis -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber monocoque
Suspension Fork
ENVE G Series Carbon Fiber Gravel Fork: Flat Mount, Fender Eyelets, Internal Routing, Through Axle
Drivetrain
Rear Derailleur
SRAM Rival
Shift Levers
SRAM Rival
Cassette
SRAM PG 1130 11-42
Crank
Praxis Zayante Alloy, 30mm spindle, 40t Alloy Ring (170mm, 172.5mm, or 175mm)
Bottom Bracket
T47 Threaded Bottom Bracket
Chain
SRAM Eagle NX with Power Lock, 12 speed
Wheels
Rims
733 Alloy or Stan’s Grail Alloy, Ibis Hubs
Tires
Schwalbe Thunder Burt 27.5” x 2.1” or Schwalbe G-One 700c x 40mm
Brakes
Brakes
SRAM Rival
Cockpit
Stem
Ibis 31.8mm (70, 80, 90, 100mm)
Handlebar
Ibis Flat Top 7075-T6 42 or 44 cm
Grips
Black EVA Bar Tape
Headset
Cane Creek 40 Headset, IS41/28.6 IS52/40
Seat
Saddle
WTB Silverado 142
Seatpost
Ibis 31.6 Aluminum, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 49cm | 53cm | 53cm | 55cm | 55cm | 58cm | 58cm | 61cm | 61cm |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.43 mm | 1.5 mm | 1.5 mm | 1.51 mm | 1.51 mm | 1.53 mm | 1.53 mm | 1.51 mm | 1.51 mm |
| Bottom Bracket Height | 279 mm | mm | 279 mm | mm | 279 mm | mm | 279 mm | mm | 279 mm | mm |
| Front Center | 587 mm | 587 mm | 591 mm | 591 mm | 601 mm | 601 mm | 617 mm | 617 mm | 637 mm | 637 mm |
| Rake | 46 mm | 46 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 75 mm | 68 mm | 67 mm | 61 mm | 64 mm | 58 mm | 64 mm | 58 mm | 64 mm | 58 mm |
| Stack | 536 mm | 536 mm | 564 mm | 564 mm | 584 mm | 584 mm | 603 mm | 603 mm | 620 mm | 620 mm |
| Reach | 374 mm | 374 mm | 377 mm | 377 mm | 386 mm | 386 mm | 395 mm | 395 mm | 410 mm | 410 mm |
| Top Tube Length | 524 mm | 524 mm | 544 mm | 544 mm | 554 mm | 554 mm | 574 mm | 574 mm | 594 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 455 mm | 525 mm | 525 mm | 550 mm | 550 mm | 575 mm | 575 mm | 605 mm | 605 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 110 mm | 135 mm | 135 mm | 155 mm | 155 mm | 175 mm | 175 mm | 195 mm | 195 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1011 mm | 1011 mm | 1015 mm | 1015 mm | 1025 mm | 1025 mm | 1041 mm | 1041 mm | 1061 mm | 1061 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 733 mm | 733 mm | 789 mm | 789 mm | 806 mm | 806 mm | 831 mm | 831 mm | 857 mm | 857 mm |
| Wheels | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 |
Model Overview
Hakka MX Rival is part of the Ibis Hakka model. Ibis launched 17 bikes of this model so far. You can easily view all of the Ibis Hakka bikes models from 2019, here.
Model range prices
Ibis Hakka MX Rival 2019 is the most economical model, with a starting price of 3299$. Ibis Hakka MX Ultegra Di2 2019 on the other hand costs 6499$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2019 and its price was 3299$. In conclusion, this bike price is 34% more expensive than the price of the average Gravel bike.
Hakka MX Rival components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the Hakka MX Rival model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
