Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Fork ENVE -
Groupset Rival, Praxis -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber monocoque
Suspension Fork
Enve Cross Disc Fork, 700c, 100x12
Drivetrain
Rear Derailleur
SRAM Rival
Shift Levers
SRAM Rival
Cassette
SRAM PG 1130 11-42
Crank
Praxis Zayante Carbon S 30mm spindle, 40t Alloy Ring 9: 170cm, 53/55/58: 172.5cm, 61: 175cm
Bottom Bracket
T47 Threaded Bottom Bracket
Chain
SRAM PC 1110
Wheels
Rims
Ibis 733 Aluminum (27.5"/650b) or Stan’s Grail (700c), Ibis Hubs
Tires
Schwalbe Thunder Burt 27.5" x 2.1" or Maxxis Rambler 700c x 40mm, EXO
Brakes
Brakes
SRAM Rival
Cockpit
Stem
Ibis 31.8mm Road 49/53: 80mm, 55: 90mm, 58: 100mm, 61: 110mm
Handlebar
Ibis Alloy Flared Bar 49/53: 42cm, 55/58/61: 44cm
Grips
Black EVA Bar Tape
Headset
Cane Creek 40: IS41/IS52/40
Seat
Saddle
WTB Silverado 142
Seatpost
Ibis Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 49cm | 53cm | 53cm | 55cm | 55cm | 58cm | 58cm | 61cm | 61cm |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.43 mm | 1.5 mm | 1.5 mm | 1.51 mm | 1.51 mm | 1.53 mm | 1.53 mm | 1.51 mm | 1.51 mm |
| Bottom Bracket Height | 279 mm | mm | 279 mm | mm | 279 mm | mm | 279 mm | mm | 279 mm | mm |
| Front Center | 587 mm | 587 mm | 591 mm | 591 mm | 601 mm | 601 mm | 617 mm | 617 mm | 637 mm | 637 mm |
| Rake | 46 mm | 46 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 75 mm | 68 mm | 67 mm | 61 mm | 64 mm | 58 mm | 64 mm | 58 mm | 64 mm | 58 mm |
| Stack | 536 mm | 536 mm | 564 mm | 564 mm | 584 mm | 584 mm | 603 mm | 603 mm | 620 mm | 620 mm |
| Reach | 374 mm | 374 mm | 377 mm | 377 mm | 386 mm | 386 mm | 395 mm | 395 mm | 410 mm | 410 mm |
| Top Tube Length | 524 mm | 524 mm | 544 mm | 544 mm | 554 mm | 554 mm | 574 mm | 574 mm | 594 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 455 mm | 525 mm | 525 mm | 550 mm | 550 mm | 575 mm | 575 mm | 605 mm | 605 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 110 mm | 135 mm | 135 mm | 155 mm | 155 mm | 175 mm | 175 mm | 195 mm | 195 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1011 mm | 1011 mm | 1015 mm | 1015 mm | 1025 mm | 1025 mm | 1041 mm | 1041 mm | 1061 mm | 1061 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 733 mm | 733 mm | 789 mm | 789 mm | 806 mm | 806 mm | 831 mm | 831 mm | 857 mm | 857 mm |
| Wheels | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 |
Model Overview
Hakka MX Rival belongs to the Ibis Hakka model. Ibis released 17 bikes variations of this model so far. Take a sneak peek at all Ibis Hakka bikes models from 2022, by clicking here.
Model range prices
Ibis Hakka MX Rival 2022 is the most economical model, with a starting price of 4599$. Ibis Hakka MX GRX 2022 on the other hand costs 4899$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 4599$. Doing a quick comparison, we notice that Hakka MX Rival price is 86.8% higher than the average cost of a Gravel bike.
Hakka MX Rival components
Fork
The ENVE is included from the factory. It has a travel distance of mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on Hakka MX Rival are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Hakka MX Rival has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
