Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 153mm -
Fork DVO Onyx SC
-
Groupset SLX -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber Monocoque
Suspension Fork
DVO Onyx D1 | 15QRx110 - 170 (27.5")
Rear Shock
Fox Float Performance Series, DPX2 with EVOL, 7.875 x 2.25
Drivetrain
Rear Derailleur
Shimano SLX M7100 Shadow Plus
Shift Levers
Shimano SLX M7100
Cassette
Shimano SLX, 10-51T
Crank
Shimano SLX M7100, 24mm spindle, 32t Alloy Ring (170mm for S/M, 175mm for L/XL)
Bottom Bracket
Threaded (73mm English threaded)
Chain
Shimano SLX M7100
Wheels
Rims
Ibis S35 Aluminum / 27.5" / Ibis Hubs
Tires
Maxxis Assegai EXO + WT 27.5" x 2.5"
Brakes
Brakes
Shimano SLX M7120 4p
Disk Rotors
Shimano SM-RT66 203/180
Cockpit
Stem
Ibis 31.8mm (40, 50, 60, 70, 80, 90mm)
Handlebar
Ibis 780mm Alloy
Grips
Lizard Skin Charger
Headset
ZS44 upper / ZS56 lower
Seat
Saddle
WTB Silverado 142
Seatpost
Bike Yoke Revive Dropper S: 125mm, M: 160mm, L/XL: 185mm. Note there is a 250lb rider weight limit on this post.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.36 mm | 1.32 mm | 1.27 mm |
| Bottom Bracket Height | 351 mm | 351 mm | 351 mm | 351 mm |
| Front Center | 761 mm | 788 mm | 820 mm | 857 mm |
| Rake | 42 mm | 42 mm | 41 mm | 41 mm |
| Trail | 126 mm | 126 mm | 126 mm | 126 mm |
| Stack | 602 mm | 618 mm | 633 mm | 647 mm |
| Reach | 434 mm | 454 mm | 479 mm | 510 mm |
| Top Tube Length | 589 mm | 613 mm | 642 mm | 676 mm |
| Seat Tube Angle | 75.8 ° | 75.8 ° | 75.8 ° | 75.8 ° |
| Seat Tube Length | 356 mm | 368 mm | 419 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 109 mm | 126 mm | 142 mm | 158 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1198 mm | 1225 mm | 1257 mm | 1294 mm |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm |
| Standover Height | 703 mm | 717 mm | 738 mm | 757 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Mojo HD5 SLX belongs to the Ibis Mojo model. There are 76 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Ibis Mojo HD5 Deore 2021 is the most affordable bike of this model and has a price of 4699$. On the other hand, Ibis Mojo XX1 AXS 2021, is the most expensive and costs 11499$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Ibis Mojo HD5 SLX price was 5699$. In conclusion, this bike price is 58.35% more expensive than the price of the average Enduro bike.
Overview of components
Fork
The fork installed on this bike is the DVO Onyx SC model. The travel on this model is 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the Fox Float Performance Series model, with a travel of 153mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The Mojo HD5 SLX 2021 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Ibis Mojo HD5 SLX is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Ibis Mojo HD5 SLX bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Ibis Mojo HD5 SLX comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
