Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset Deore -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Fox Float 34 Performance Series 130mm, 29”, 110x15
Rear Shock
Fox Performance Series Float DPS with EVOL, 190mm x 45mm S/M: Light Tune, L/XL: Standard Tune
Drivetrain
Rear Derailleur
Shimano Deore M6100 Shadow Plus
Shift Levers
Shimano Deore M6100
Cassette
Shimano Deore M6100 10-51
Crank
Shimano Deore M6100 24mm spindle, 30t Alloy Ring S/M: 170mm, L/XL: 175mm
Bottom Bracket
Threaded BB (73mm BSA)
Chain
Shimano Deore M6100
Wheels
Rims
Ibis S35 Aluminum / 29" / Ibis Hubs
Tires
Maxxis DHR2 29" x 2.4" Exo TR (front), Maxxis Dissector 29" x 2.4" Exo TR (rear)
Brakes
Brakes
Shimano Deore 6100 Series
Disk Rotors
Shimano SM-RT66, 180mm
Cockpit
Stem
Ibis 31.8mm S/M: 40mm, L/XL: 50mm S/M frame comes with 40mm, L/XL comes with 50mm length stem.
Handlebar
Ibis 780mm Alloy
Grips
Lizard Skin Charger
Headset
ZS44 upper / ZS56 lower
Seat
Saddle
WTB Silverado 142
Seatpost
KS Rage-i Dropper S: 125mm, M: 150mm, L/XL: 170mm S frame comes with 125mm, M with 150mm, L/XL 170mm seatpost.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.36 mm | 1.31 mm | 1.26 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Trail | 114 mm | 114 mm | 114 mm | 114 mm |
| Stack | 601 mm | 615 mm | 624 mm | 633 mm |
| Reach | 427 mm | 452 mm | 477 mm | 502 mm |
| Top Tube Length | 576 mm | 605 mm | 632 mm | 660 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 368 mm | 381 mm | 418 mm | 482 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 90 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1159 mm | 1190 mm | 1219 mm | 1248 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 678 mm | 705 mm | 724 mm | 761 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Ripley AF Deore belongs to the Ibis Ripley model. Ibis launched 59 bikes of this model so far. You can easily view all of the Ibis Ripley bikes models from 2021, here.
Model range prices
The most economical model, the Ibis Ripley AF Deore 2021 has a starting price of 3199$. Ibis Ripley XX1 AXS 2021 on the other hand is the most expensive at 11499$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Ibis released this model in 2021, its price was 3199$. In conclusion, this bike price is 15.82% higher than the price of the average Trail bike.
Ripley AF Deore components
Fork
The Fox Performance Float 34 is included from the factory. It has a travel distance of 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is Fox Performance Series Float DPS with EVOL, with a travel distance of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When leaving the production line, the Ripley AF Deore model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Ripley AF Deore comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Ibis Ripley AF Deore includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
