Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset GX, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber Monocoque
Suspension Fork
Fox Float 34 Performance Series 130mm, 29”, 15QR
Rear Shock
Fox Float DPS Performance Series EVOL 7.25 x 1.75
Drivetrain
Rear Derailleur
SRAM Eagle GX 12 Speed
Shift Levers
SRAM Eagle GX 12 Speed
Cassette
SRAM XG 1275 10-50 12 speed
Crank
SRAM Descendant Alloy 175, DUB spindle, 32t Alloy Ring (170,175)
Bottom Bracket
SRAM DUB BSA
Chain
SRAM Eagle GX with Power Lock, 12 speed
Wheels
Rims
Ibis 938 Alloy, Ibis Hubs
Tires
Schwalbe Nobby Nic 29” x 2.6”
Brakes
Brakes
Shimano Deore 2 Piston
Disk Rotors
Shimano SM-RT66 180
Cockpit
Stem
Ibis 31.8mm (50, 60, 70, 80, 90mm)
Handlebar
Ibis 780mm Alloy
Grips
Lizard Skins Charger Evo
Headset
Cane Creek 40: ZS44/EC49
Seat
Saddle
WTB Silverado 142
Seatpost
Bike Yoke Revive Dropper (125, 160 or 185mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.5 mm | 1.46 mm | 1.41 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Trail | 97 mm | 97 mm | 97 mm | 97 mm |
| Stack | 608 mm | 622 mm | 628 mm | 635 mm |
| Reach | 386 mm | 414 mm | 431 mm | 451 mm |
| Top Tube Length | 549 mm | 603 mm | 622 mm | 643 mm |
| Seat Tube Angle | 75 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 386 mm | 419 mm | 470 mm | 521 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 77.5 mm | 93 mm | 102 mm | 107 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1147 mm | 1143 mm | 1170 mm | 1190 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm | 44 mm |
| Standover Height | 704 mm | 743 mm | 743 mm | 755 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Ripley LS GX Eagle completes the Ibis Ripley model. There are 59 bikes that carry this model name. You can easily view all of the Ibis Ripley bikes models from 2019, here.
Model range prices
Ibis Ripley LS NX Eagle 2019 is the cheapest bike model and costs 4099$. Ibis Ripley LS XX1 Eagle 2019 is the most expensive one and costs 9399$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2019 and its price was 4899$. In conclusion, this bike price is 77.37% higher than the price of the average Trail bike.
Ripley LS GX Eagle components
Fork
The fork installed on this bike is the Fox Performance Float 34 model. The travel on this model is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Ibis Ripley LS GX Eagle bike has the Fox Float DPS Performance Series EVOL 7.25 x 1.75 model installed, and has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the Ripley LS GX Eagle model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Ripley LS GX Eagle comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Ibis Ripley LS GX Eagle includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
