Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset NX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX 34 Float Performance Series, Boost
Rear Shock
FOX Float DPS Performance Series EVOL, 7.25" x 1.75"
Drivetrain
Rear Derailleur
SRAM NX, long cage, black, 11-speed
Front Derailleur
N/A
Shift Levers
SRAM NX, trigger, black, 11-speed
Cassette
SRAM PG 1130, 11-42 tooth, 11-speed
Crank
SRAM NX, 175mm length
Bottom Bracket
73mm (BSA) english thread
Chain
SRAM CN PC1110, 114 link with PowerLock
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
Ibis Boosted
Rear Hub
Ibis Boosted
Rims
Ibis 938 Very Wide Aluminum Asymmetric Wheelset, 34mm inner width
Spokes
Sapim
Tires
Schwalbe Nobby Nic 2.6"
Brakes
Brakes
SRAM Level with centerline 180mm front/160mm rear rotors, post mount
Brake Levers
SRAM Level
Cockpit
Stem
Ibis 3D, forged 7075 aluminum, 31.8mm bar, 28.6mm steerer, 50mm - 90mm lengths
Handlebar
Ibis T76 7075 aluminum, 780mm, 20mm rise
Grips
Lizard Skins, Ibis Logo
Headset
Cane Creek 40 ZS44/EC49
Seat
Saddle
Ibis custom, chromoly rails
Seatpost
KS LEV-Si Dropper, length options of 100mm, 125mm, or 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.46 mm | 1.41 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm |
| Stack | 621 mm | 627 mm | 634 mm |
| Reach | 413 mm | 430 mm | 450 mm |
| Top Tube Length | 602 mm | 621 mm | 642 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 419 mm | 470 mm | 521 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 93 mm | 102 mm | 107 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1142 mm | 1169 mm | 1189 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm |
| Standover Height | 742 mm | 742 mm | 752 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Ripley LS NX belongs to the Ibis Ripley model. Ibis launched 59 bikes of this model so far. Take a sneak peek at all Ibis Ripley bikes models from 2018, by clicking here.
Model range prices
Ibis Ripley LS NX 2018 is the cheapest bike model and costs 5856$. Ibis Ripley LS XX1 Eagle 2018 is the most expensive one and costs 9299$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Ibis released this model in 2018, its price was 5856$. Comparing this to the average Trail bike price, we see that the price is 112.02% higher.
Overview of components
Fork
The Ripley LS NX comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is FOX Float DPS Performance Series EVOL, with a travel distance of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The Ripley LS NX 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Ibis Ripley LS NX comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
