Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 147mm -
Fork Marzocchi Bomber Z1 Coil
-
Groupset Deore -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Marzocchi Bomber Z1 Coil, 160mm, 44mm offset, 29”, 110x15mmMedium spring installed. More info here.
Rear Shock
Marzocchi Bomber Air, 210 x 55
Drivetrain
Rear Derailleur
Shimano Deore M6100 Shadow Plus
Shift Levers
Shimano Deore M6100
Cassette
Shimano Deore M6100 10-51
Crank
Shimano Deore M6120 24mm spindle, 30t Alloy RingS/M: 170mm, L/XL: 175mm
Bottom Bracket
Threaded (73mm English threaded)
Chain
Shimano Deore M6100
Wheels
Rims
Blackbird Send Alloy (Send I front, Send II rear) / 29" / Ibis Hubs
Tires
Maxxis Assegai 29" x 2.5" EXO+ casing, 120tpi (front), Maxxis DHR II 29" x 2.4" EXO+ casing, 60tpi (rear)
Brakes
Brakes
Shimano Deore M6120 4 Piston
Cockpit
Stem
Ibis 31.8mmS/M: 40mm, L/XL: 50mm
Handlebar
Ibis Aluminum, 780mm
Grips
Lizard Skin Charger Evo
Headset
ZS44 upper / ZS56 lower
Seat
Saddle
WTB Silverado
Seatpost
KS Rage-i DropperS: 125mm, M: 150mm, L/XL: 170mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.35 mm | 1.32 mm | 1.3 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 752 mm | 783 mm | 804 mm | 829 mm |
| Rake | 43 mm | 43 mm | 43 mm | 42 mm |
| Trail | 114 mm | 114 mm | 114 mm | 114 mm |
| Stack | 615 mm | 622 mm | 631 mm | 644 mm |
| Reach | 433 mm | 460 mm | 477 mm | 497 mm |
| Top Tube Length | 575 mm | 605 mm | 634 mm | 657 mm |
| Seat Tube Angle | 77 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 368 mm | 380 mm | 432 mm | 483 mm |
| Head Tube Angle | 64.9 ° | 64.9 ° | 64.9 ° | 64.9 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1187 mm | 1218 mm | 1239 mm | 1264 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 707 mm | 752 mm | 752 mm | 762 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Ripmo AF Deore completes the Ibis Ripmo model. Ibis released 69 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Ibis Ripmo AF GX 2023 is the most affordable bike of this model and has a price of 3599$. On the other hand, Ibis Ripmo V2S XX1 AXS 2023, is the most expensive and costs 11699$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Ibis released this model in 2023, its price was 3599$. If we compare this with the average Trail bike cost we notice that the price is 30.3% higher.
Ripmo AF Deore components
Fork
The Ripmo AF Deore comes factory-installed with the Marzocchi Bomber Z1 Coil fork. This has a travel range of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Marzocchi Bomber Air, with a travel distance of 147mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the Ripmo AF Deore model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the Ripmo AF Deore. Therefore, climbing or descending will be a breeze.
